Cam switch in housing SK40 OB13 SK40-2.8211\OB13ZC

local index:
ALO035SPAM
Catalog No:
SK40-2.8211\OB13ZC
EAN code:
5907723072251
Manufacturer: SPAMEL
Surge voltage [kV]: 6
Rated current [A]: 50
Rated switching current [A]: 40
Price:
36,95 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Cam switch in housing SK40 OB13

Technical data

  • Surge voltage [kV]
    6
  • Rated switching current [A]
    40
  • Rated current [A]
    50
  • Insulation voltage [V]
    690

Other technical data

  • Model
    Reverser
  • With zero (off) position
    Yes
  • Rated permanent current Iu
    40 A
  • Degree of protection (IP), front side
    IP65
  • Number of auxiliary contacts as normally open contact
    0
  • Suitable for floor mounting
    Yes
  • Suitable for distribution board installation
    No
  • Complete device in housing
    Yes
  • Type of control element
    Turn button
  • Number of poles
    3
  • With retraction in 0-position
    No
  • Rated operation power at AC-3, 400 V
    12 kW
  • Number of auxiliary contacts as normally closed contact
    0
  • Number of auxiliary contacts as change-over contact
    0
  • Suitable for front mounting
    No
  • Suitable for intermediate mounting
    No
  • Housing material
    Plastic
  • Type of electrical connection of main circuit
    Screw connection
