Cam switch 63A, L-O-R reversing switch, in OB16 housing SK63-3.8368\OB16
local index:
ALO010SPAM
Catalog No:
SK63-3.8368\OB16
EAN code:
5907723111110
Manufacturer:
SPAMEL
Continuous current [A]: 63
Level of security: IP65
Rated operational power at AC-3, 400 V [kW]: 18
Price:
66,65 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
The new SK63 and SK100 cam switches, which are also switch disconnectors, extend the offer of the SK switch family with further, higher current ranges, respectively 63 A and 100 A. The segmented construction of these switches with double cams allows you to create any switching programs depending on the position of the drive knob.
Technical data
-
Continuous current [A]63
-
Rated operational power at AC-3, 400 V [kW]18
-
Level of securityIP65
Other technical data
-
ModelReverser
-
With zero (off) positionYes
-
Rated permanent current Iu63 A
-
Degree of protection (IP), front sideIP65
-
Number of auxiliary contacts as normally open contact0
-
Suitable for floor mountingYes
-
Suitable for distribution board installationNo
-
Complete device in housingYes
-
Type of control elementTurn button
-
Number of poles3
-
With retraction in 0-positionNo
-
Rated operation power at AC-3, 400 V18 kW
-
Number of auxiliary contacts as normally closed contact0
-
Number of auxiliary contacts as change-over contact0
-
Suitable for front mountingNo
-
Suitable for intermediate mountingNo
-
Housing materialPlastic
-
Type of electrical connection of main circuitScrew connection
