Cam switch 63A, 0-1 four-pole switch, in OB16 housing SK63-2.8210\OB16

Index local:
ALO027SPAM
Numéro de catalogue:
SK63-2.8210\OB16
Code EAN:
5907723111103
Producteur: SPAMEL
Continuous current [A]: 63
Level of security: IP65
Rated operational power at AC-3, 400 V [kW]: 18
Prix:
48,95 €
gross / pcs.
(y compris la TVA 23%)
Livraison en 3h
jusqu'à 2 semaines (jours ouvrables)
Ramassage en 1h
Quantité pcs.
(plusieurs:
1
)
Ajouter au presse-papiers
Imprimer

Description du produit

The new SK63 and SK100 cam switches, which are also switch disconnectors, extend the offer of the SK switch family with new, higher current ranges, respectively 63 A and 100 A. The segmented design of these switches with double cams allows you to create any switching programs depending on the position of the drive knob.

Données techniques

  • Continuous current [A]
    63
  • Rated operational power at AC-3, 400 V [kW]
    18
  • Level of security
    IP65

Autres données techniques

  • Model
    Reverser
  • With zero (off) position
    Yes
  • Rated permanent current Iu
    63 A
  • Degree of protection (IP), front side
    IP65
  • Number of auxiliary contacts as normally open contact
    0
  • Suitable for floor mounting
    Yes
  • Suitable for distribution board installation
    No
  • Complete device in housing
    Yes
  • Type of control element
    Turn button
  • Number of poles
    4
  • With retraction in 0-position
    No
  • Rated operation power at AC-3, 400 V
    18 kW
  • Number of auxiliary contacts as normally closed contact
    0
  • Number of auxiliary contacts as change-over contact
    0
  • Suitable for front mounting
    No
  • Suitable for intermediate mounting
    No
  • Housing material
    Plastic
  • Type of electrical connection of main circuit
    Screw connection
