Cam switch 40A, four-pole 1-0-2 switch disconnector, panel-mounted, gray face, black knob ŁK40-4.8396\P03

local index:
ALK200SPAM
Catalog No:
ŁK40-4.8396\P03
EAN code:
5907723124929
Manufacturer: SPAMEL
Color: Black
Rated insulation voltage [V]: 690
Continuous current [A]: 40
Price:
46,64 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Cam switch 40A, four-pole 1-0-2 switch disconnector, panel-mounted, gray face, black knob

Technical data

  • Color
    Black
  • Continuous current [A]
    40
  • Accurate color
    Black
  • Rated insulation voltage [V]
    690
  • Level of security
    IP65

Other technical data

  • Model
    Reverser
  • With zero (off) position
    Yes
  • Rated permanent current Iu
    40 A
  • Degree of protection (IP), front side
    IP65
  • Number of auxiliary contacts as normally open contact
    0
  • Suitable for floor mounting
    Yes
  • Suitable for distribution board installation
    No
  • Complete device in housing
    No
  • Type of control element
    Turn button
  • Number of poles
    4
  • With retraction in 0-position
    No
  • Rated operation power at AC-3, 400 V
    20 kW
  • Number of auxiliary contacts as normally closed contact
    0
  • Number of auxiliary contacts as change-over contact
    0
  • Suitable for front mounting
    No
  • Suitable for intermediate mounting
    Yes
  • Housing material
    Plastic
  • Type of electrical connection of main circuit
    Screw connection
