Cam switch 32A, three-pole 1-0-2 switch, in OB3 enclosure ŁK32R-3.8380\OB3
local index:
ALO031SPAM
Catalog No:
ŁK32R-3.8380\OB3
EAN code:
5907723024267
Price:
34,90 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Cam switches are devices for mechanical switching on and off of currents with the possibility of implementing a specific switching program in the function of turning the knob. Cam switches are used in housings of low voltage electrical installations, especially as circuit breakers, disconnectors, switches and control switches. Cam switches can be installed indoors (pollution degree 3 - industrial use) at -40...+70°C.
Technical data
-
ColorGray
-
Accurate colorGray
-
Continuous current [A]32
Other technical data
-
ModelReverser
-
With zero (off) positionYes
-
Rated permanent current Iu32 A
-
Degree of protection (IP), front sideIP65
-
Number of auxiliary contacts as normally open contact0
-
Suitable for floor mountingYes
-
Suitable for distribution board installationNo
-
Complete device in housingYes
-
Type of control elementTurn button
-
Number of poles3
-
With retraction in 0-positionNo
-
Rated operation power at AC-3, 400 V17 kW
-
Number of auxiliary contacts as normally closed contact0
-
Number of auxiliary contacts as change-over contact0
-
Suitable for front mountingNo
-
Suitable for intermediate mountingNo
-
Housing materialPlastic
-
Type of electrical connection of main circuitScrew connection
