Acti9 IHP+ 1C time switch CCT15838

local index:
APC029SCHN
Catalog No:
CCT15838
EAN code:
3606480769238
Manufacturer: SCHNEIDER ELECTRIC
Height [mm]: 90
Price:
162,32 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
2 weeks
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Acti9 IHP+ 1C time switch

Technical data

  • Height [mm]
    90
  • PKWIU
    27.12.40.0

Other technical data

  • Mounting method
    DIN rail
  • Supply voltage
    250 ... 250 V
  • Frequency supply voltage
    50 ... 60 Hz
  • Autonomy in years
    10
  • Text guidance in display
    No
  • With memory card
    No
  • 24 h program
    Yes
  • Annual program
    Yes
  • Impulse program
    Yes
  • Astro program
    No
  • Hour meter
    No
  • Quartz controlled
    Yes
  • Radio-controlled (DCF77)
    No
  • Shortest switching time channel 1
    0.02 min
  • Automatic switching summer-/winter time
    Yes
  • External pushbutton input
    Yes
  • Nominal switching current at 250 V AC
    4 A
  • Degree of protection (IP)
    IP20
  • Width
    18 mm
  • Depth
    66 mm
  • Number of channels
    1
  • Voltage type (supply voltage)
    AC
  • Autonomy in hours
    87600
  • Accuracy per day
    0.5 s
  • External programming
    Yes
  • 60 min program
    Yes
  • Weekly program
    Yes
  • Holiday program
    Yes
  • Cycle program
    Yes
  • Random program
    Yes
  • Mains synchronous
    No
  • Radio-controlled
    No
  • GPS (global positioning system)
    No
  • Shortest switching time channel 2
    0.02 min
  • Suitable for manual operation
    Yes
  • Switching preselection
    No
  • Potential free switch contact
    Yes
  • Width in number of modular spacings
    1
  • Height
    90 mm
