800A four-pole load switch HA460
Místní index:
ALM059HAGE
Katalogové číslo.:
HA460
EAN kód:
3250613119706
Cena:
4 902,78 zł
gross / kusů.
(včetně DPH 23%)
Na zakázku
Přidat do žádosti o cenovou nabídku
Vytisknout
Dotaz na výrobek
Popis produktu
Isolating Load Switch. It is perfectly adapted to meet current requirements resulting from everyday electrical installation practice.
Current:
- Current carrying capacity of AC21 in category A: 800 A
- Rated operational current (AC23), category A: 800 A
- Current carrying capacity AC21 category B: 800 A
- Allowable current load AC22 category A : 800 A
- Allowable current load AC22 category B: 800 A
- Rated operational current (AC23) category B: 800 A
- Short-circuit current with gI fuses -gG: 50 kA
- Rated short-time withstand current Icw: 35 kA
- Rated short-time withstand current 1s: 35 kA
Power :
- Rated power below 660V, 50Hz: 185kW
- Active power below 380/415V, 50Hz: 450kW
- Rated switching power at 400V rated voltage for AC1: 526 kW
- Total power loss at rated current: 199.1 W
- Power loss per pole at rated current: 39 .7 W
Technické údaje
-
Number of poles4
-
Rated current [A]800
-
power loss [W]199.1
-
Connection typeVice
-
Rated switching voltage [V]380/415
-
Rated operational current [A]800
-
PKWIU27.12.22.0
-
Rated insulation voltage [V]1000
-
Level of securityIP00
-
Power loss per pole [W]39.7
-
Mechanical durability (number of cycles)4000
-
Rated surge voltage [V]8000
-
Conductor cross-section (wire) [mm²]2 x 300
Další technické údaje
-
Version as main switchYes
-
Version as safety switchYes
-
Version as reversing switchYes
-
Rated operating voltage380 ... 415 V
-
Rated permanent current at AC-21, 400 V800 A
-
Rated operation power at AC-23, 400 V360 kW
-
Conditioned rated short-circuit current Iq50 kA
-
Number of auxiliary contacts as normally closed contact0
-
Number of auxiliary contacts as change-over contact0
-
Motor drive integratedYes
-
Device constructionBuilt-in device fixed built-in technique
-
Suitable for front mounting 4-holeYes
-
Suitable for distribution board installationYes
-
Colour control elementBlack
-
InterlockableYes
-
Degree of protection (IP), front sideIP00
-
Version as maintenance-/service switchYes
-
Version as emergency stop installationYes
-
Max. rated operation voltage Ue AC415 V
-
Rated permanent current Iu800 A
-
Rated short-time withstand current lcw35 kA
-
Switching power at 400 V526 kW
-
Number of poles4
-
Number of auxiliary contacts as normally open contact0
-
Motor drive optionalYes
-
Voltage release optionalYes
-
Suitable for floor mountingYes
-
Suitable for front mounting centreYes
-
Suitable for intermediate mountingYes
-
Type of control elementLong turning handle
-
Type of electrical connection of main circuitCable clamp
Podrobnosti o výrobci
-
VýrobceHager Electro S.A.S.
-
AdresaFR 67215 Obernai 123 boulevard d’Europe Francja
-
E-mail
Velkoobjemová balení
| Typ obalu | Pakiet | Paleta |
| Množství | 1 kusů. | 6 kusů. |
| Hmotnost (kg) | 12,195 | 73,170 |
| Objem (m3) | - | 0,458 |
| Šířka (m) | 0,425 | - |
| Délka (m) | 0,295 | - |
| Hloubka (m) | 0,609 | - |
