25A Cam Switch, 0-1-2-3 Circuit Switch, Enclosed, Three Position ŁK25R-2.8445\OB2

Lokaler Index:
ALK163SPAM
Katalognummer:
ŁK25R-2.8445\OB2
EAN-Code:
5907723003187
Hersteller: SPAMEL
Color: Gray
Continuous current [A]: 25
Level of security: IP65
Preis:
109,04 zł
gross / stk.
(inklusive MwSt 23%)
Lieferung in 3h
bis zu 2 Wochen (Arbeitstage)
Abholung in 1 Stunde
Menge stk.
(mehrere:
1
)
Zur Angebotsanfrage hinzufügen
Zur Zwischenablage hinzufügen
Drucken

Produktbeschreibung

Cam switches are devices for mechanical switching on and off of currents with the possibility of implementing a specific switching program as a function of turning the knob. Cam switches are used in housings of low voltage electrical installations, especially as circuit breakers, disconnectors, switches and control switches. Cam switches can be installed indoors (pollution degree 3 - industrial use) at -40...+70°C.

Technische Daten

  • Color
    Gray
  • Level of security
    IP65
  • Accurate color
    Gray
  • Continuous current [A]
    25
  • Rated operational power at AC-3, 400 V [kW]
    13

Weitere technische Daten

  • Model
    Reverser
  • With retraction in 0-position
    No
  • Rated operation power at AC-3, 400 V
    13 kW
  • Number of auxiliary contacts as normally closed contact
    0
  • Number of auxiliary contacts as change-over contact
    0
  • Suitable for front mounting
    No
  • Suitable for intermediate mounting
    No
  • Housing material
    Plastic
  • Type of electrical connection of main circuit
    Screw connection
  • With zero (off) position
    Yes
  • Rated permanent current Iu
    25 A
  • Degree of protection (IP), front side
    IP65
  • Number of auxiliary contacts as normally open contact
    0
  • Suitable for floor mounting
    Yes
  • Suitable for distribution board installation
    No
  • Complete device in housing
    Yes
  • Type of control element
    Turn button
