160A three-pole switch disconnector for external handle RSI-3160\W01
Indice locale:
ALI006SPAM
Numero di catalogo:
RSI-3160\W01
Codice EAN:
5907723009370
Produttore:
SPAMEL
Rated insulation voltage [V]: 690
Continuous current [A]: 160
Level of security: IP20
Prezzo:
449,96 zł
gross / pezzi
(inclusa IVA 23%)
Consegna in 3 ore
Raccolta in 1h
Quantità pezzi
(multiplo:
1
)
Aggiungi alla richiesta di preventivo
Aggiungi agli appunti
Stampa
Chiedi informazioni sul prodotto
Descrizione del prodotto
160A three-pole switch disconnector for external handle. RSI compact switch disconnectors are designed for operation in circuits with a rated voltage of up to 690 V, in the AC-21A...AC-23A utilization categories and in DC circuits with a voltage of up to 220 V. The disconnectors can be installed in closed rooms (3 degree of pollution - industrial purpose), at the temperature from -40°C to +70°C.
Dati tecnici
-
Rated insulation voltage [V]690
-
Level of securityIP20
-
Continuous current [A]160
Altri dati tecnici
-
Version as main switchYes
-
Version as safety switchNo
-
Version as reversing switchNo
-
Max. rated operation voltage Ue AC690 V
-
Rated operation power at AC-23, 400 V30 kW
-
Number of poles3
-
Number of auxiliary contacts as normally open contact0
-
Motor drive optionalNo
-
Voltage release optionalNo
-
Suitable for floor mountingYes
-
Suitable for front mounting centreNo
-
Suitable for intermediate mountingNo
-
InterlockableNo
-
Degree of protection (IP), front sideIP20
-
Version as maintenance-/service switchNo
-
Version as emergency stop installationYes
-
Number of switches1
-
Rated permanent current Iu160 A
-
Conditioned rated short-circuit current Iq10 kA
-
Number of auxiliary contacts as normally closed contact0
-
Number of auxiliary contacts as change-over contact0
-
Motor drive integratedNo
-
Device constructionBuilt-in device fixed built-in technique
-
Suitable for front mounting 4-holeNo
-
Suitable for distribution board installationNo
-
Type of control elementTurn button
-
Type of electrical connection of main circuitScrew connection
Dettagli del produttore
-
ProduttoreS.I. Spamel
-
Indirizzo56- 416 Twardogóra Wojska Polskiego 3 Polska
