1600A four-pole load switch HA464
local index:
ALM061HAGE
Catalog No:
HA464
EAN code:
3250613119720
Price:
4079,23 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Isolating Load Switch. It is perfectly adapted to meet current requirements resulting from everyday electrical installation practice.
Current:
- Current carrying capacity of AC21 in category A: 1600 A
- Rated operational current (AC23), category A: 1000 A
- Current carrying capacity AC21 category B: 1600 A
- Allowable current load AC22 category A : 1250 A
- Allowable current load AC22 Category B: 1250 A
- Rated operational current (AC23) Category B: 1000 A
- Short-circuit current with gI fuses -gG: 50 kA
- Rated short-time withstand current Icw: 50 kA
- Rated short-time withstand current 1s: 50 kA
Power :
- Rated power below 660V, 50Hz: 475kW
- Active power below 380/415V, 50Hz: 560kW
- Rated switching power at 400V rated voltage for AC1: 1053 kW
- Total power loss at rated current: 366 W
- Power loss per pole at rated current: 122 W< /li>
Technical data
-
Number of poles4
-
Rated current [A]1600
-
power loss [W]366
-
Connection typeVice
-
Rated switching voltage [V]380/415
-
Rated operational current [A]1000
-
PKWIU27.12.22.0
-
Rated insulation voltage [V]1000
-
Level of securityIP00
-
Power loss per pole [W]122
-
Mechanical durability (number of cycles)3000
-
Rated surge voltage [V]8000
-
Conductor cross-section (wire) [mm²]6 x 240
Other technical data
-
Version as main switchYes
-
Version as safety switchYes
-
Version as reversing switchYes
-
Rated operating voltage380 ... 415 V
-
Rated permanent current at AC-21, 400 V1600 A
-
Rated operation power at AC-23, 400 V562 kW
-
Conditioned rated short-circuit current Iq50 kA
-
Number of auxiliary contacts as normally closed contact0
-
Number of auxiliary contacts as change-over contact0
-
Motor drive integratedYes
-
Device constructionBuilt-in device fixed built-in technique
-
Suitable for front mounting 4-holeYes
-
Suitable for distribution board installationYes
-
Colour control elementBlack
-
InterlockableYes
-
Degree of protection (IP), front sideIP00
-
Version as maintenance-/service switchYes
-
Version as emergency stop installationYes
-
Max. rated operation voltage Ue AC415 V
-
Rated permanent current Iu1600 A
-
Rated short-time withstand current lcw50 kA
-
Switching power at 400 V1053 kW
-
Number of poles4
-
Number of auxiliary contacts as normally open contact0
-
Motor drive optionalYes
-
Voltage release optionalYes
-
Suitable for floor mountingYes
-
Suitable for front mounting centreYes
-
Suitable for intermediate mountingYes
-
Type of control elementLong turning handle
-
Type of electrical connection of main circuitCable clamp
Manufacturer details
-
ManufacturerHAGER POLO Sp. z o. o.
-
Address43-100 Tychy Fabryczna 10
-
E-mail
-
Tax identification number6460015532
-
GLN5900009931532
Bulk packaging
| A kind of package | Karton | Paleta | |
| Quantity | 1 pcs. | 1 pcs. | 8 pcs. |
| Weight (kg) | 15,999 | 16,400 | 153,200 |
| Width (m) | 0,285 | 0,400 | 0,800 |
| Length (m) | 0,420 | 0,245 | 0,620 |
| Depth (m) | 0,540 | 0,580 | 1,200 |
