Advantages:
- Power switch
- Range of controlled temperature from -19.5°C to +70°C.
- Contact with a switching capacity of 16A/230V.
- Large, backlit display with clear menu.
- Mounting on a standard DIN rail.
- Additional functions: sensor calibration, temperature reduction, antifreeze function, setting scale limiter.
- Working mode thermostat/power regulator
- Heating/cooling operation mode
- ON/OFF or PWM control
Technical data:
Supply voltage: 230V AC ±10% 50/60Hz
Standby power consumption: 0.5W
SPST output contact: 16A / 230V AC (resistive load) 1A / 230V (inductive load)
Built-in protection: 2-pole; 16A
Initial protection: 16A
Control: PWM/PI or ON/OFF
PWM cycle: adjustable from 10 to 60 min.
Hysteresis (ON/OFF only): from +0.3°C to +10.0°C
Controlled temperature range: from -19.5°C to +70°C
Temperature limiter range: -19.5°C to +70°C
Measurement accuracy: 0.4°C
Operating temperature: from -20°C to +55°C
Storage temperature: -20°C to +70°C
Relative value of temperature reduction: from -19.5°C to +30°C
Reduction for the power regulator: 0 - 100%
Frost protection (absolute): 0°C to +10°C
Freeze protection regulator: 0 – 100%
Temperature sensor: standard 3m/max. up to 100m
