TEHALIT.BK Channel end piece steel tub BKWD 200x(80-120) steel BKWDE200080

local index:
TAK0G8TEHA
Catalog No:
BKWDE200080
EAN code:
4012002241530
Manufacturer: TEHALIT
Halogen free: Yes
Length [mm]: 215
Color: Silver
Price:
108,35 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Channel end piecefor co-horizontal duct system with bottom tub for damp-cleaned floors BKWD, tehalit.BK series.

Characteristics of the series:

The tehalit.BK co-horizontal duct system is used to run cables and other installations, e.g. water or heating pipes in floors, anywhere in the room. The tehalit.BK system can be used with flat screeds from 30 mm.

Technical data

  • Halogen free
    Yes
  • Color
    Silver
  • Family
    TEHALIT.BK
  • Height [mm]
    80
  • Leveling range
    80/120
  • Length [mm]
    215
  • Material
    Galvanized steel sheet
  • Width [mm]
    200
  • Accurate color
    galvanized
  • PKWIU
    25.99.29.0

Other technical data

  • Width
    200 mm
  • Suitable for subfloor duct overhead open
    Yes
  • Suitable for subfloor duct overhead closed
    Yes
  • Height
    80 mm
  • Suitable for subfloor duct countersunk (closed)
    No
  • Levelling range
    80 ... 120 mm

Bulk packaging

A kind of package Karton Paleta
Quantity 1 pcs. 1 pcs. 32 pcs.
Weight (kg) 1,534 2,136 93,352
Width (m) 0,125 0,275 0,800
Length (m) 0,080 0,200 1,050
Depth (m) 0,220 0,275 1,200
