PVC wiring trunking 20x35mm 2 chambers white LF2003609016

Name: PVC wiring trunking 20x35mm 2 chambers white
Brand: TEHALIT
SKU: TKP143TEHA
Price: 5.46 PLN
Availability: InStock

local index:

TKP143TEHA

Catalog No:

LF2003609016

EAN code:

4012740011730

PVC wiring trunking 20x35mm 2 chambers white

Click on the photo to enlarge

Manufacturer: TEHALIT

Length [mm]: 2000

Color: White

Material: PVC

See full description

Large-size product

Price:

5,46 €

gross / pcs.

(including VAT 23%)

Delivery in 3h

Accessible 81 pcs.

Quantity pcs.

(multiplicity:

)

Add to clipboard

Ask about the product

Product description Technical data Bulk packaging

Product description

PVC electrical installation trunking 20x35mm 2 chambers 2m long, white. Thanks to the integrated connectors, laying a single trunking is easy. Electrical installation ducts will be used to route electrical cables in basements, production halls or garages.

Technical data

Length [mm]

2000
Material

PVC
Level of security

IP30
Height [mm]

20
Usable cross-section [mm²]

420

Color

White
Installation

Surface-mounted
Width [mm]

35
Degree of mechanical protection

IK07
Number of chambers

2

Other technical data

Height

20 mm
Length

2000 mm
Material

Plastic
Halogen free

No
Suitable for circuit integrity

No
Transparent

No
Number of permanent partitions

1
Type of fastening

Bottom perforation
With cable fixing clip

No
With duct connector

No
Pre-stamping

No

Width

33 mm
Useful cross section

420 mm²
Material quality

Polyvinyl chloride (PVC)
Surface protection

Untreated
Colour

White
RAL-number

9016
Number of plug-in partitions

0
Cover model

Loose
With protective foil

No
Delivery on roll

No

Bulk packaging

A kind of package		Karton	Paleta
Quantity	1 pcs.	20 pcs.	1280 pcs.
Weight (kg)	0,230	11,240	744,360
Width (m)	0,034	0,180	0,800
Length (m)	0,020	0,090	1,640
Depth (m)	1,000	2,045	2,045
