LED driver for single-color strips NEXTEC SKY SC 12-24V 8A 2.4GHz Wi-Fi PD027279

local index:
AUD008POLT
Catalog No:
PD027279
EAN code:
5908293927279
Manufacturer: POLTRONIC
Frequency [GHz]: 2.4
Length [mm]: 97
Power [W]: 96 | 192
Price:
14,00 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Accessible 19 pcs.
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

  • 2.4GHz technology, the system works up to 30m
  • Constant voltage receiver with single-channel output
  • Receiver compatible with remote controls for LED strip lighting
  • Multiple zones can be controlled separately or synchronously with an infinite number of receivers in each zone
  • One RF lighting controller can work with ten remotes
  • One receiver can transmit a signal from a remote control to another receiver within 30m
  • The total remote control distance is about 100m
  • The receiver can be controlled via Wi-Fi - using an application installed on a mobile device with IOS or Android systems
  • The receiver works with the amplifier

The controller works with the remote control for single color tapes PD027224.

Technical data

  • Frequency [GHz]
    2.4
  • Power [W]
    96 192
  • Rated current [A]
    8
  • Level of security
    IP20
  • Durability [h]
    100000
  • Height [mm]
    18
  • Range [m]
    thirty
  • Length [mm]
    97
  • Rated voltage [V]
    12 24
  • Family
    NEXTEC SKY
  • Width [mm]
    33
  • Type
    RF / WiFi
  • Temperature range [°C]
    from -30 to +55
