Current transformer ISS-1 600/5; 2.5VA class 0.2S ISS-1-30 600/5 KL 0,2S 2,5VA

Name: Current transformer ISS-1 600/5; 2.5VA class 0.2S
Brand: FANINA
SKU: AUK015FANI
Price: 34.96 PLN
Availability: InStock

local index:

AUK015FANI

Catalog No:

ISS-1-30 600/5 KL 0,2S 2,5VA

EAN code:

5901384238414

Current transformer ISS-1 600/5; 2.5VA class 0.2S

Click on the photo to enlarge

Manufacturer: FANINA

Rated primary current In [A]: 600

Nominal secondary current Is [A]: 5

See full description

Outlet

Stan produktu: Towar jest fabrycznie nowy, nieuszkodzony. Może nosić ślady długiego magazynowania.

Opakowanie: Towar może zostać dostarczony w opakowaniu zastępczym lub w lekko uszkodzonym oryginalnym opakowaniu.

Dostępność: Tylko w ilości dostępnej na magazynie.

Outlet

Price:

34,96 €

gross / pcs.

(including VAT 23%)

Last lowest price: 35,37 € gross

Base price: 41,03 € gross -15%

Accessible 1 pcs.

Quantity pcs.

(multiplicity:

1

)

It is not possible to add more of this product to the cart. Goods at a promotional price can only be purchased in the quantity available in stock.

Add to clipboard

Print

Ask about the product

Product description Technical data

Product description

TECHNICAL DATA: Rated frequency f = 50Hz The highest permissible voltage of the device Um = 0.72kV Rated test voltage at mains frequency 3kV Insulation class B Extended current range ext. 120% Rated short-time thermal current Ith = 60 x Ipr Rated dynamic current Idyn = 2.5 x Ith Housing: self-extinguishing polyamide reinforced with glass fiber class HB (according to UL-94) Working temperature: -35 ÷ + 55oC Power Sr: 2.5; 5 FS: 5
