Current transformer 600/1A 5VA class 1 LVZWE600
local index:
AUK066HAGE
Catalog number:
LVZWE600
EAN code:
4049857125296
Price:
231,02 zł
gross / pcs.
(including VAT 23%)
On request
Quantity pcs.
(multiplicity:
1
)
Add to inquiry
Add to clipboard
Print
Ask about the product
Product description
Current transformer for LVSG NH1/2/3 series fuse switch disconnectors:
- 600/1A,
- mounting: busbar system ,
- accuracy class: 1,
- rail size: Rundleiter d= max. 21mm.
Technical data
-
Rated frequency [Hz]60
-
Depth [mm]30.1
-
Input power [VA]5
-
FamilyLV
-
Width [mm]59.5
-
Height [mm]63.5
-
Accuracy [s]1
-
Opening diameter [mm]21
-
Rated insulation voltage [kV]3
-
Conductor cross-section (wire) [mm²]1.5 - 4
-
Length [mm]59.5
-
Power [VA]5
-
InstallationOn the TH-35 rail
-
Level of securityIP10
-
Connection typeScrew connection
-
Operating temperature range [°C]from -40 to 40
-
Gear600;1
-
storage temperature [°C]from -40 to 75
-
Wire cross-section (cord) [mm²]1.5 - 4
-
PKWIU27.11.42.0
Other technical data
-
ModelAttachable current transformer
-
Rated secondary current1 A
-
Overcurrent limiting factorFS 5
-
Opening diameter21 mm
-
Number of primary inputs1
-
Rated primary current600 A
-
Rated secondary apparent power5 VA
-
With shock protectionYes
-
With copper railNo
Manufacturer details
-
ManufacturerHager Electro GmbH & Co KG
-
AddressDE 66440 Blieskastel Zum Gunterstal Niemcy
-
E-mail
Bulk packaging
| A kind of package | Karton | Pakiet | Paleta |
| Quantity | 1 pcs. | 60 pcs. | 1980 pcs. |
| Weight (kg) | 0,176 | 10,940 | 386,020 |
| Width (m) | 0,060 | 0,290 | 0,800 |
| Length (m) | 0,050 | 0,170 | 1,050 |
| Depth (m) | 0,070 | 0,400 | 1,200 |
