Current transformer 250/5A 5VA class 1 LVZW250

local index:
AUK041HAGE
Catalog No:
LVZW250
EAN code:
4049857123131
Manufacturer: HAGER
Rated frequency [Hz]: 60
Length [mm]: 59.5
Depth [mm]: 30.1
Price:
47,90 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 10 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Current transformer for LVSG NH1/2/3 series fuse switch disconnectors:

  • 250/5A,
  • mounting: busbar system ,
  • accuracy class: 1,
  • rail size: Rundleiter d= max. 21mm.

Technical data

  • Rated frequency [Hz]
    60
  • Depth [mm]
    30.1
  • Input power [VA]
    5
  • Family
    LV
  • Width [mm]
    59.5
  • Height [mm]
    63.5
  • Accuracy [s]
    1
  • Opening diameter [mm]
    21
  • Rated insulation voltage [kV]
    3
  • Conductor cross-section (wire) [mm²]
    1.5 - 4
  • Length [mm]
    59.5
  • Power [VA]
    5
  • Installation
    On the TH-35 rail
  • Level of security
    IP10
  • Connection type
    Screw connection
  • Operating temperature range [°C]
    from -40 to 40
  • Gear
    250;5
  • storage temperature [°C]
    from -40 to 75
  • Wire cross-section (cord) [mm²]
    1.5 - 4
  • PKWIU
    27.11.42.0

Other technical data

  • Model
    Attachable current transformer
  • Rated secondary current
    5 A
  • Overcurrent limiting factor
    FS 5
  • Opening diameter
    21 mm
  • Number of primary inputs
    1
  • Rated primary current
    250 A
  • Rated secondary apparent power
    5 VA
  • With shock protection
    Yes
  • With copper rail
    No

Bulk packaging

A kind of package Karton Paleta
Quantity 1 pcs. 1 pcs. 2000 pcs.
Weight (kg) 0,160 0,165 355,000
Width (m) 0,060 0,060 0,800
Length (m) 0,064 0,050 0,670
Depth (m) 0,030 0,075 1,200
