El12 and HAGER
Current transformer 150/5A 2.5VA class 1 LVZW150
local index:
AUK040HAGE
Catalog No:
LVZW150
EAN code:
4049857123049
Click on the photo to enlarge
Manufacturer:
HAGER
Rated frequency [Hz]:
60
Length [mm]:
59.5
Depth [mm]:
30.1
See full description
Price:
50,15 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 10 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to cart
Add to clipboard
Print
Ask about the product
Product description
Technical data
Bulk packaging
Product description
Current transformer 150/5A 2.5VA class 1
Technical data
Rated frequency [Hz]
60
Depth [mm]
30.1
Input power [VA]
2.5
Level of security
IP10
Connection type
Screw connection
Operating temperature range [°C]
from -40 to 40
Gear
150;5
storage temperature [°C]
from -40 to 75
Wire cross-section (cord) [mm²]
1.5 - 4
PKWIU
27.11.42.0
Length [mm]
59.5
Power [VA]
2.5
Installation
On the TH-35 rail
Width [mm]
59.5
Height [mm]
63.5
Accuracy [s]
1
Opening diameter [mm]
21
Rated insulation voltage [kV]
3
Conductor cross-section (wire) [mm²]
1.5 - 4
Other technical data
Model
Attachable current transformer
Rated secondary current
5 A
Overcurrent limiting factor
FS 5
Opening diameter
21 mm
Number of primary inputs
1
Rated primary current
150 A
Rated secondary apparent power
2.5 VA
With shock protection
Yes
With copper rail
No
Bulk packaging
A kind of package
Karton
Paleta
Quantity
1 pcs.
1 pcs.
2000 pcs.
Weight (kg)
0,150
0,160
345,000
Width (m)
0,060
0,070
0,800
Length (m)
0,064
0,104
1,000
Depth (m)
0,030
0,210
1,200
