KNX SYSTEM K.5 CO2 sensor with humidity measurement and aluminum temperature controller 75441371
local index:
PRC009HAGE
Catalog No:
75441371
EAN code:
4011334451044
Price:
563,59 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
CO2 sensorwith humidity measurement and temperature controller, KNX system series. Main design line: KNX - Berker K.5.
Controls and indicators
- with programming button and red programming LED
Connections
- with 2 independent digital inputs for potential-free contacts
Connection< /strong>
- bus connection via connection terminals
Equipment
- heating or cooling it is possible in 2 modes
- for heating or air conditioning
- for single room control
Series characteristics:
The economic use of buildings is gaining in importance, especially in terms of functionality and energy efficiency. When we consider private buildings, there is a need for safety, security, comfort and well-being. A modern electrical installation with an intelligent KNX system creates ideal conditions to meet all these requirements by integrating the automation management of the entire building.
Technical data
-
Halogen freeNO
-
SurfaceMatt
-
Operating temperature range [°C]from -5 to 45
-
Bus current consumption (data transmission) [mA]12.5
-
MaterialPlastic Metal
-
FamilyKNX SYSTEM
-
Operating voltage via DC bus [V]21 - 32
-
PKWIU26.51.70.0
Other technical data
-
Bus system KNXYes
-
Bus system radio frequentNo
-
Bus system PowernetNo
-
Radio frequent bidirectionalNo
-
Mounting methodFlush-mounted
-
With anti-theft/dismantling protectionYes
-
With displayNo
-
Material qualityOther
-
Surface finishingMatt
-
RAL-number (similar)9006
-
Manual set point settingNo
-
Parallel-service possibleNo
-
With bus connectionYes
-
Bus system KNX-RF (Radio Frequent)No
-
Bus system LONNo
-
Other bus systemsNone
-
Assembly arrangementBasic element with central cover plate
-
With local operationNo
-
With LED indicationNo
-
MaterialOther
-
Surface protectionAnodised
-
ColourAluminium
-
TransparentNo
-
Presence buttonNo
-
Degree of protection (IP)IP20
-
Class of the temperature controlIV
Manufacturer details
-
ManufacturerHAGER POLO Sp. z o. o.
-
Address43-100 Tychy Fabryczna 10
-
E-mail
-
Tax identification number6460015532
-
GLN5900009931532
Bulk packaging
| A kind of package | Karton | Pakiet | Paleta | |
| Quantity | 1 pcs. | 1 pcs. | 36 pcs. | 1152 pcs. |
| Weight (kg) | 0,142 | 0,167 | 6,277 | 220,854 |
| Width (m) | 0,070 | 0,084 | 0,300 | 0,800 |
| Length (m) | 0,050 | 0,070 | 0,225 | 1,050 |
| Depth (m) | 0,070 | 0,085 | 0,400 | 1,200 |
