Three-phase bidirectional indirect meter, semi-indirect, M-BUS, 100(5)A; MID LE-03MB-CT
local index:
NPL030FIFQ
Catalog No:
LE-03MB-CT
EAN code:
5908312599814
Manufacturer:
F&F
Installation: On the TH-35 rail
Level of security: IP51
Working temperature [°C]: -25÷55
Price:
223,20 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Three-phase bidirectional indirect meter, semi-indirect, M-BUS, 100(5)A; MID
Technical data
-
InstallationOn the TH-35 rail
-
Working temperature [°C]-25÷55
-
Level of securityIP51
-
PKWIU26.51.63.0
Other technical data
-
Type of meterElectronic
-
Max. current (Imax)6 A
-
Accuracy classB
-
ModelMeasurement transformer
-
Suitable forPurchase/supply
-
Tariff controlExternal
-
Escapement mechanismYes
-
ApprovalMeasuring Instruments Directive
-
Pulse typeS0
-
Type of indicationDigital
-
Width in number of modular spacings4
-
EEC40 signatureNo
-
Degree of protection (IP)IP20
-
Nominal current (In)5 A
-
Nominal voltage (Un) N-L230 ... 400 V
-
Pole typeThree conductor
-
Energy typeEffective power and blind power
-
Tariff typeOne-tariff
-
Measurement type load profileNo
-
CalibratedYes
-
Pulse outputElectrical
-
Pulse rate0.01 ... 100 Imp/kWh (kvarh)
-
Mounting methodDRA (DIN-rail adapter)
-
Type of interfaceM-bus (wired)
-
With lock codeYes
Manufacturer details
-
ManufacturerF&F FILIPOWSKI SPÓŁKA KOMANDYTOWA
-
Address95-200 UL. KONSTANTYNOWSKA 79/81
-
E-mail
-
Tax identification number7310005314
Bulk packaging
| A kind of package | Sztuka |
| Quantity | 1 pcs. |
| Width (m) | 0,076 |
| Length (m) | 0,100 |
| Depth (m) | 0,075 |
