agardio.measure 1-phase electricity meter, 3x80A 4M, pulse output. ECP180T

Name: agardio.measure 1-phase electricity meter, 3x80A 4M, pulse output.
Brand: HAGER
SKU: NPL023HAGE
Price: 1377.66 PLN
Availability: BackOrder

local index:

NPL023HAGE

Catalog number:

ECP180T

EAN code:

3250612230402

agardio.measure 1-phase electricity meter, 3x80A 4M, pulse output.

Click on the photo to enlarge

Manufacturer: HAGER

Price:

1 377,66 zł

gross / pcs.

(including VAT 23%)

up to 10 weeks

On request

Quantity pcs.

(multiplicity:

)

Add to inquiry

Add to clipboard

Ask about the product

Technical data Manufacturer details Bulk packaging Files to download

Technical data

PKWIU

26.51.63.0

Other technical data

Type of meter

Electronic
Max. current (Imax)

80 A
Frequency

45 ... 65 Hz
Pole type

Single phase
Energy type

Effective power and blind power
Tariff type

Two-tariff
Measurement type load profile

No
Calibrated

Yes
Pulse type

S0
Type of indication

Digital
Width in number of modular spacings

4
With lock code

No
Degree of protection (IP)

IP20

Nominal current (In)

80 A
Nominal voltage (Un) N-L

92 ... 276 V
Accuracy class

B
Model

Direct measurement
Suitable for

Purchase/supply
Tariff control

External
Escapement mechanism

Yes
Pulse output

Electrical
Pulse rate

1 ... 1000 Imp/kWh (kvarh)
Mounting method

DRA (DIN-rail adapter)
EEC40 signature

No
Number of positions total (counter)

9

Manufacturer details

Manufacturer

Hager Electro S.A.S.
Address

FR 67215 Obernai 123 boulevard d’Europe Francja
E-mail

wsparcie.klienta@hager.com

Bulk packaging

A kind of package	Karton	Pakiet	Paleta
Quantity	1 pcs.	24 pcs.	576 pcs.
Weight (kg)	0,437	10,900	284,600
Width (m)	0,090	0,310	0,800
Length (m)	0,080	0,230	1,090
Depth (m)	0,110	0,360	1,200
