SPD Varistor surge arrester T2 1P TNC 20kA 40kA 1.35kV SPB115
local index:
AOG008HAGE
Catalog No:
SPB115
EAN code:
3250615514875
Manufacturer:
HAGER
Family: SPD
Price:
66,73 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
SPD Varistor surge arrester T2 1P TNC 20kA 40kA 1.35kV
Technical data
-
FamilySPD
-
PKWIU27.12.23.0
Other technical data
-
System configuration TNYes
-
System configuration TN-C-SNo
-
System configuration TTNo
-
Number of conductors (without earthing)1
-
Max. discharge surge current (8/20)40 kA
-
Max. continuous voltage AC275 V
-
Voltage protection level1.35 kV
-
Short-circuit breaking capacity (Isccr)25 kA
-
Mounting methodDIN rail (top hat rail) 35 mm
-
Max. conductor cross section solid (solid, stranded)35 mm²
-
With remote signalling contactYes
-
Category type 2Yes
-
System configuration TN-CYes
-
System configuration TN-SNo
-
System configuration otherNo
-
Nominal discharge surge current (8/20)20 kA
-
Nominal voltage AC240 V
-
Max. PV-voltage0 V
-
Voltage protection level L-N1.35 kV
-
Integrated backup fuseNo
-
Construction size1 modular spacing
-
Max. conductor cross section flexible (fine-strand)25 mm²
-
Signalling at the deviceOptical
-
Degree of protection (IP)IP20
Bulk packaging
| A kind of package | Karton | Pakiet | Paleta | |
| Quantity | 1 pcs. | 1 pcs. | 42 pcs. | 1008 pcs. |
| Weight (kg) | 0,110 | 0,140 | 6,315 | 174,560 |
| Width (m) | 0,018 | 0,085 | 0,315 | 0,800 |
| Length (m) | 0,099 | 0,050 | 0,210 | 0,990 |
| Depth (m) | 0,066 | 0,115 | 0,360 | 1,200 |
