SPD Varistor surge arrester T1+T2 MOV 4P TN-S/TT 50kA 50kA 1.2kV SPA931

local index:
AOG011HAGE
Catalog No:
SPA931
EAN code:
3250615515186
Manufacturer: HAGER
Family: SPD
Price:
242,08 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
2 weeks
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

SPD Varistor surge arrester T1+T2 MOV 4P TN-S/TT 50kA 50kA 1.2kV

Technical data

  • Family
    SPD
  • PKWIU
    27.12.23.0

Other technical data

  • System configuration DC
    No
  • System configuration TN
    No
  • System configuration TN-C-S
    Yes
  • System configuration TT
    Yes
  • Number of poles
    4
  • Max. continuous voltage AC
    335 V
  • Voltage protection level
    1.2 kV
  • Voltage protection level L-PE
    1.7 kV
  • Mounting method
    DIN rail (top hat rail) 35 mm
  • Max. conductor cross section solid (solid, stranded)
    35 mm²
  • Remote signalling
    Yes
  • Test class
    Type 1 + 2
  • Degree of protection (IP)
    IP20
  • System configuration IT
    No
  • System configuration TN-C
    No
  • System configuration TN-S
    Yes
  • System configuration other
    No
  • Lightning impulse current (10/350 µs)
    12.5 kA
  • Nominal voltage AC
    415 V
  • Voltage protection level L-N
    1.2 kV
  • Voltage protection level N-PE
    1.7 kV
  • Construction size
    4 modular spacing
  • Max. conductor cross section flexible (fine-strand)
    25 mm²
  • Signalling at the device
    Optical
  • Integrated backup fuse
    No

Bulk packaging

A kind of package Karton Pakiet Paleta
Quantity 1 pcs. 1 pcs. 22 pcs. 528 pcs.
Weight (kg) 0,640 0,670 15,270 389,480
Width (m) 0,071 0,080 0,315 0,800
Length (m) 0,099 0,085 0,210 0,990
Depth (m) 0,078 0,110 0,360 1,200
