SPD Varistor surge arrester for photovoltaics T2 MOV 3P PV 15kA 3.7kV 1kVDC SPV340
local index:
AOC051HAGE
Catalog No:
SPV340
EAN code:
3250615514967
Manufacturer:
HAGER
Family: SPD
Price:
102,77 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
SPD Varistor surge arrester for photovoltaics T2 MOV 3P PV 15kA 3.7kV 1kVDC
Technical data
-
FamilySPD
-
PKWIU27.12.23.0
Other technical data
-
System configuration DCYes
-
System configuration otherYes
-
Nominal discharge surge current (8/20)15 kA
-
Nominal voltage DC1000 V
-
Max. continuous voltage DC1170 V
-
Voltage protection level3.7 kV
-
Short-circuit breaking capacity (Isccr)2 kA
-
Mounting methodDIN rail (top hat rail) 35 mm
-
Max. conductor cross section solid (solid, stranded)35 mm²
-
With remote signalling contactNo
-
Category type 2Yes
-
System configuration TN-C-SYes
-
Number of conductors (without earthing)2
-
Nominal voltage AC1000 V
-
Max. continuous voltage AC1170 V
-
Max. PV-voltage0 V
-
Voltage protection level L-N3.7 kV
-
Integrated backup fuseNo
-
Construction size3 modular spacing
-
Max. conductor cross section flexible (fine-strand)25 mm²
-
Signalling at the deviceOptical
-
Degree of protection (IP)IP20
Manufacturer details
-
ManufacturerHAGER POLO Sp. z o. o.
-
Address43-100 Tychy Fabryczna 10
-
E-mail
-
Tax identification number6460015532
-
GLN5900009931532
Bulk packaging
| A kind of package | Karton | Pakiet | Paleta | |
| Quantity | 1 pcs. | 1 pcs. | 27 pcs. | 648 pcs. |
| Weight (kg) | 0,310 | 0,330 | 9,365 | 247,760 |
| Width (m) | 0,053 | 0,085 | 0,315 | 0,800 |
| Length (m) | 0,099 | 0,060 | 0,210 | 1,050 |
| Depth (m) | 0,066 | 0,110 | 0,360 | 1,200 |
