SPD Surge arrester T1 combined 3P TN-C, 75 kA, Up≤1.5 kV SPN800
local index:
AOC042HAGE
Catalog No:
SPN800
EAN code:
3250615660909
Price:
1060,06 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
SPD Surge arrester T1 combined 3P TN-C, 75 kA, Up≤1.5 kV
Technical data
-
Rated frequency [Hz]60
-
Number of poles3
-
InstallationOn the TH-35 rail
-
Level of securityIP20
-
Operating temperature range [°C]from -40 to 60
-
Number of modules6
-
BeaconFailure indication
-
Wire cross-section (cord) [mm²]35
-
PKWIU27.12.23.0
-
Depth [mm]83
-
Tightening torque [Nm]3.6
-
Maximum continuous operating voltage [V]255
-
Width [mm]108
-
Rated switching voltage [V]230/400
-
Remote contactNO
-
storage temperature [°C]From -40 to 80
-
Conductor cross-section (wire) [mm²]35
Other technical data
-
Max. continuous voltage AC255 V
-
Voltage protection level1.5 kV
-
Follow current extinguishing capability50 kA
-
With remote signalling contactNo
-
Signalling at the deviceOptical
-
Degree of protection (IP)IP20
-
Nominal voltage AC400 V
-
Voltage protection level L-N1.5 kV
-
Mounting methodDIN rail (top hat rail) 15 mm
-
ExhaustingNo
-
Category type 1Yes
Bulk packaging
| A kind of package | Karton | Pakiet | Paleta | |
| Quantity | 1 pcs. | 1 pcs. | 8 pcs. | 192 pcs. |
| Weight (kg) | 0,970 | 1,015 | 8,560 | 228,440 |
| Width (m) | 0,108 | 0,115 | 0,313 | 0,800 |
| Length (m) | 0,065 | 0,097 | 0,210 | 0,990 |
| Depth (m) | 0,090 | 0,125 | 0,360 | 1,200 |
