Power limiter ETIMAT T 3P 10A 002181060

Внутрішній артикул:
AOC030ETIP
№ каталоговий:
002181060
Код EAN:
5904722987739
Виробник: ETI POLAM
Number of poles: 3
Rated voltage [V]: 230
Terminal capacity: 1-25mm2, max. 3Nm
Ціна:
171,33 zł
gross / шт.
(з ПДВ 23%)
503,91 zł gross/кг.
Доставка за 3 години
до 2 тижнів (робочі дні)
Самовивіз через 1 год
Кількість шт.
(багаторазовий:
1
)
Додати до запиту на пропозицію
Додати в буфер обміну
Роздрукувати

Опис товару

The ETIMAT T power limiter (overcurrent circuit breaker) is intended for installation in the switchgear as pre-meter protection. The purpose of this protection is selective switching off in relation to the Z4 overcurrent protection of the recipient. The rated current of the ETIMAT T power limiter is matched to the connection/contractual power of the recipient. ETIMAT T power limiters in terms of their rated currents replace selective circuit breakers. The ETIMAT T power limiter is an overcurrent circuit breaker without a short-circuit element and has only an overload (thermal) element. Sealed circuit breaker (blocked access to its current terminals) is installed in the switchgear so that its driving lever is available to the recipient, who in the event of spontaneous activation due to exceeding the connection capacity or for other reasons, can independently switch it on without summoning the power company team.

Advantages:

  •  limits (limits) electricity consumption
  •  ensures overload selectivity with other devices overcurrent
  •  can be sealed.

Технічні дані

  • Number of poles
    3
  • Terminal capacity
    1-25mm2, max. 3Nm
  • Level of security
    IP20
  • Weight [g]
    340
  • Short-circuit breaking capacity [kA]
    6
  • PKWIU
    27.12.22.0
  • Rated voltage [V]
    230
  • Rated current [A]
    10
  • Working temperature [°C]
    from -25 to +50
  • Compliance with standards
    PN - EN 60898-12007
  • Insulation voltage [V]
    500

Інші технічні дані

  • Mounting method
    DIN rail
  • Rated permanent current Iu
    10 A
  • Conditioned rated short-circuit current Iq
    6 kA
  • Short-circuit current limiter
    No

Інформація про виробника

  • Виробник
    ETI Polam Sp. z o.o.
  • Адреса
    06-100 Pułtusk Jana Pawła II 18 Polska
  • Електронна пошта

Об'ємна упаковка

Свого роду пакет Pudełko Pudełko
Кількість 4 шт. 36 шт.
Вага (кг) 1,440 -
Об'єм (м3) 0,002 -
Ширина (м) 0,092 -
Довжина (м) 0,220 -
Глибина (м) 0,078 -
