1802 5 CU BigBar potential equalization rail / 5 connections 5015830

Name: 1802 5 CU BigBar potential equalization rail / 5 connections
Brand: OBO BETTERMANN
SKU: AON014OBOB
Price: 376.95 PLN
Availability: BackOrder

local index:

AON014OBOB

Catalog number:

5015830

EAN code:

4012195002253

1802 5 CU BigBar potential equalization rail / 5 connections

Click on the photo to enlarge

Manufacturer: OBO BETTERMANN

Price:

376,95 zł

gross / pcs.

(including VAT 23%)

2 weeks

On request

Quantity pcs.

(multiplicity:

6

)

Add to inquiry

Add to clipboard

Print

Ask about the product

Technical data Manufacturer details Bulk packaging Files to download

Technical data

Other technical data

Construction type

Surface mounting fix
Insulator

Yes
Width

40 mm
Number of connections round conductor total

5
Number of connections round conductor 10 mm

0
Number of connections flat conductor 30 mm

0
Number of connections conductor to 6 mm² fixed

0
Number of connections conductor to 25 mm² fixed

0
Material of contact rail

Copper

Model

Only clamp
Height

5 mm
Length

246 mm
Number of connections round conductor 8 mm

0
Number of connections round conductor 8-10 mm

0
Number of connections flat conductor 40 mm

0
Number of connections conductor to 16 mm² fixed

0
Number of connections conductor to 95 mm² fixed

0
Material of clamp

Copper

Manufacturer details

Manufacturer

OBO Bettermann Holding GmbH & Co. KG
Address

58710 Menden Hüingser Ring 52 Niemcy
E-mail

oferty@obo.pl

Bulk packaging

A kind of package	Torebka	Karton	Paleta
Quantity	1 pcs.	6 pcs.	672 pcs.
Weight (kg)	0,801	4,999	582,388
Volume (m3)	0,000	0,005	0,912
Width (m)	0,040	0,188	0,800
Length (m)	0,246	0,290	1,200
Depth (m)	0,028	0,089	0,950
