TYTAN 2 LED BASIC Industrial luminaire 75W 10000lm 4000K IP66 matt gray 908767

local index:
OWF738LENA
Catalog No:
908767
EAN code:
5905963908767
Manufacturer: LENA LIGHTING
Light color [K]: 3500-4800 (natural)
Length [mm]: 1432
Color: Gray
Large-size product
Price:
90,71 €
gross / pcs.
(including VAT 23%)
Last lowest price: 93,95 € gross
Base price: 163,39 € gross -44%
Delivery in 3h
Accessible 30 pcs.
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Characteristics:
TYTAN 2 LED BASIC is a basic line of lamps that are an excellent alternative to traditional fluorescent lamps.

The lamp was designed from scratch. New solutions were introduced to improve light distribution and temperature balance. New LED modules contribute to high luminous efficiency up to 126 lm/W. This guarantees the achievement of the required level of lighting and significant energy savings.

The lamp uses many improvements that facilitate and accelerate assembly: a solution consisting in integrating the lampshade with the LED module, the lampshade suspension system, adjustable handles ensuring assembly tolerance +/- 40mm. As standard, it is equipped with durable clips made of stainless steel (INOX). The lamp body and the lampshade are resistant to UV radiation.

Application:
The multifunctional LED lamp is designed for use in areas with high requirements for dust and water resistance. Particularly recommended for lighting public utility facilities, including hospital and educational facilities, halls, garages, passages, warehouses, shops, food industry and commercial and service facilities related to food, industrial facilities (factories, laboratories), warehouses, car parks (underground and multi-storey buildings), sports stadiums, transport terminals and underground passages. The lamp is ideal for new lighting applications as well as for replacing traditional fluorescent luminaires with energy-saving LED solutions. Its structure is suitable for surface and suspended mounting.

Technical data

  • Light color [K]
    3500-4800 (natural)
  • Color
    Gray
  • Power [W]
    75
  • Family
    TITANIUM 2 LED BASIC
  • luminous flux [lm]
    10000
  • Degree of mechanical protection
    IK09
  • Color Temperature [K]
    4000
  • Length [mm]
    1432
  • Material
    PC
  • Installation
    Surface-mounted
  • Level of security
    IP66
  • Dimensions [mm]
    1432x85x80
  • Lampshade type
    Matt
  • EEL - energy efficiency class
    A+

Other technical data

  • Lamp type
    LED exchangeable
  • Material
    Plastic
  • With control gear
    Yes
  • Dimming 1-10 V
    No
  • Dimming DMX
    No
  • Dimming potentiometer (integrated)
    No
  • Dimming LineSwitch
    No
  • Dimming mains voltage modulation
    No
  • Dimming phase cut-on
    No
  • Dimming RF
    No
  • Dimming Touch and Dim
    No
  • Dimming with push-button
    No
  • Suitable for emergency lighting
    No
  • Degree of protection (IP)
    IP66
  • With movement sensor
    No
  • Width
    85 mm
  • Length
    1432 mm
  • With light source
    Yes
  • Housing colour
    Grey
  • Dimming 0-10 V
    No
  • Dimming DALI
    No
  • Dimming DSI
    No
  • Ściemniacz GPRS
    No
  • Dimming manufacturer's proprietary system
    No
  • Dimming phase cut-off
    No
  • Dimming programmable
    No
  • Dimming Sine Wave Reduction
    No
  • Dimming Zigbee
    No
  • No dim function
    Yes
  • Rated life time L70/B50 at 25 °C
    82000 h
  • With switch
    No
  • Colour temperature
    4000 ... 4000 K
  • Height/depth
    80 mm
