302189
0
PANEL 600 Ceiling luminaire 230V 36W 4320lm IP54 WW 120st white 4058075149489
local index:
OWE010LEDV
Catalog No:
4058075149489
EAN code:
4058075149489
Price:
191,47 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Light fitting with square edges and a high degree of protection, from the PANEL 600 series.
Area of application:< /p>
- Corridors,
- Offices,
- Meeting rooms,
- Reception areas,
- Hospitals,< /li>
- Laboratories.
- Suitable for flush ceiling systems with a module size of 600 x 600 mm.
Product benefits:
- Up to 50% energy savings (compared to luminaires using fluorescent lamps),
- Lightweight guide plate with a microstructure of non-yellowing material ensures long life, < li> Easy and fast installation.
Product features:
- Operating mode: ECG,
- Ambient temperature: -10 ... + 40 ° C.
Technical data
-
Light color [K]2000-3500 (warm)
-
beam angle [°]120
-
ColorWhite
-
Power [W]36
-
Rated voltage [V]230
-
Luminous efficiency [lm/W]120
-
luminous flux [lm]4320
-
Mounting width [mm]575
-
Color Temperature [K]3000
-
Lampshade materialPMMA
-
PKWIU27.40.25
-
Length [mm]595
-
Protection classII
-
MaterialAluminum
-
InstallationSurface Flush-mounted
-
FamilyPANEL 600
-
Level of securityIP54
-
Width [mm]595
-
Height [mm]12.6
-
cri (ra)>80
-
Mounting length [mm]575
Other technical data
-
Suitable for wall mountingYes
-
Suitable for ceiling mountingYes
-
Suitable for surface mountingNo
-
Suitable for workplace according to EN 12464-1No
-
With light sourceYes
-
Housing colourWhite
-
Type of gridMatt
-
Nominal voltage220 ... 240 V
-
Type of control gearElectronic ballast
-
Dimming 0-10 VNo
-
Dimming DALINo
-
Dimming DSINo
-
Ściemniacz GPRSNo
-
Dimming manufacturer's proprietary systemNo
-
Dimming phase cut-offNo
-
Dimming programmableNo
-
Dimming Sine Wave ReductionNo
-
Dimming ZigbeeNo
-
Ściemniacz zależny od statecznikaNo
-
Light distributorDiffuser lens/optic/panel
-
Beam angleExtreme wide beam >80°
-
Klasa efektywności energetycznej zamontowanego źródła światłaA++, A+, A (LED)
-
Rated life time L70/B50 at 25 °C80000 h
-
Żywotność znamionowa L80/B50 przy 25 °C60000 h
-
Żywotność znamionowa L90/B50 przy 25 °C35000 h
-
Impact strengthIK03
-
Suitable for emergency lightingYes
-
With light sensorNo
-
With air slotsNo
-
Max. system power36.00 W
-
Colour of lightWhite
-
Colour rendering index CRI80-89
-
Power factor0.90
-
Height/depth12.6 mm
-
Built-in length575.0 mm
-
Built-in height/depth50.0 mm
-
Number of poles2
-
Suitable for suspended mountingYes
-
Suitable for built-in mountingYes
-
Suitable for light line configurationNo
-
Lamp typeLED not exchangeable
-
Housing materialAluminium
-
Material coverPlastic, opal
-
Voltage typeAC
-
Prąd znamionowy LED przy zasilaniu prądem stałym190 ... 190 mA
-
With control gearYes
-
Dimming 1-10 VNo
-
Dimming DMXNo
-
Dimming potentiometer (integrated)No
-
Dimming LineSwitchNo
-
Dimming mains voltage modulationNo
-
Dimming phase cut-onNo
-
Dimming RFNo
-
Dimming Touch and DimNo
-
Dimming with push-buttonNo
-
No dim functionYes
-
Light sharingSymmetric
-
Light outletDirect
-
Żywotność znamionowa L70/B10 przy 25 °C80000 h
-
Rated life time L80/B10 at 25 °C60000 h
-
Żywotność znamionowa L90/B10 przy 25°C35000 h
-
Degree of protection (IP)IP54
-
Protection classII
-
With movement sensorNo
-
Covering of the luminaire with thermally insulating material possibleNo
-
Filament test according to IEC 60695-2-11650 °C - 30 s
-
Rated luminous flux according to IEC 62722-2-14320 lm
-
Colour temperature3000 ... 3000 K
-
Luminaire efficacy120 lm/W
-
Width595.0 mm
-
Length595.0 mm
-
Built-in width575.0 mm
-
Type of wiringEnding
-
Connection typeOther
Bulk packaging
| A kind of package | Skrzynia | Karton | |
| Quantity | 1 pcs. | 1 pcs. | 4 pcs. |
| Weight (kg) | 3,200 | 3,495 | 14,830 |
| Volume (m3) | - | 0,025 | 0,113 |
| Width (m) | - | 0,060 | 0,270 |
| Length (m) | - | 0,630 | 0,650 |
| Depth (m) | - | 0,640 | 0,650 |
Files to download
