High Bay E LED 200W 840 60° IP65 Multi Lumen 4099854417788

Indeks lokalny:
OWF045LEDV
Nr katalogowy:
4099854417788
Kod EAN:
4099854417788
Producent: LEDVANCE
Color Rendering Index [CRI]: Ra>80
Frequency [Hz]: 50-60
Cable length [mm]: 300
Bestsellery
Cena:
306,27 zł
gross / szt.
(w tym VAT 23%)
Cena producenta: 557,55 zł gross
Dostawa do 3h
Dostępne 55 szt.
Odbiór za 1h
Ilość szt.
(wielokrotność:
1
)
Dodaj do zapytania ofertowego
Dodaj do schowka
Drukuj

Opis produktu

The High Bay E LED 200W 840 60° IP65 luminaire is a modern lighting solution designed to effectively illuminate spaces with high ceilings, such as industrial halls, warehouses, and logistics centers. Thanks to LED technology, the luminaire offers high luminous efficiency and a long service life, translating into significant energy savings and reduced operating costs. The product has a nominal power of 200W, adjustable to 150W and 100W, allowing you to adjust the light intensity to your individual needs. Luminous flux is 30,000 lm, 22,500 lm, and 15,000 lm, respectively, ensuring adequate lighting even in large and high-ceilinged spaces. A color temperature of 4000K (neutral white) and a 60° beam angle guarantee uniform and comfortable lighting, eliminating glare. The luminaire has an IP65 rating, ensuring full protection against dust and resistance to water jets from any direction. Additionally, the Multi Lumen function allows users to select the power level before installation, increasing flexibility and enabling optimal adaptation to the specific needs of the illuminated space. The use of high-quality materials and modern LED technology ensures a long lifespan of the fixture, estimated at 70,000 hours at 35°C (L70-B50), minimizing the need for maintenance and light source replacement. Furthermore, the product is covered by a 5-year warranty, demonstrating the high quality and reliability of the device. The High Bay LED 200W 840 60° IP65 is an ideal solution for industrial facilities that require efficient, energy-efficient, and durable lighting that ensures work comfort and user safety.

Dane techniczne

  • Color Rendering Index [CRI]
    Ra>80
  • Cable length [mm]
    300
  • beam angle [°]
    60
  • Color
    Black
  • Material
    aluminum
  • Power [W]
    200/150/100
  • Rated voltage [V]
    220-240
  • Output current [mA]
    850
  • Luminous efficiency [lm/W]
    150
  • Level of security
    IP65
  • Darkening
    NO
  • Weight [kg]
    1.9
  • Electrical endurance (number of cycles)
    100000
  • Application
    Inside
  • Rated output current [mA]
    850
  • Minimum operating temperature [°C]
    -20
  • Frequency [Hz]
    50-60
  • Beam angle [°]
    90
  • Protection class
    AND
  • Maximum operating temperature [°C]
    45
  • Housing material
    PC
  • Installation
    Wall
  • Initial starting current [A]
    117
  • Family
    High Bay E
  • Mounting method
    Ceiling hook
  • luminous flux [lm]
    30000/22500/15000
  • Diameter [mm]
    280
  • Height [mm]
    150
  • Power range [W]
    200/150/100
  • Degree of mechanical protection
    IK08
  • Color Temperature [K]
    4000
  • luminous flux [lm/m]
    150

Pozostałe dane techniczne

  • Mounting method
    Other
  • With light source
    Yes
  • Suitable for auxiliary lamp
    No
  • Housing material
    Aluminium
  • Voltage type
    AC
  • Type of control gear
    Electronic ballast
  • With control gear
    Yes
  • Dimming 1-10 V
    No
  • Dimming DMX
    No
  • Dimming phase cut-off
    No
  • Dimming potentiometer (integrated)
    No
  • Dimming manufacturer's proprietary system
    No
  • Dimming programmable
    No
  • Dimming Sine Wave Reduction
    No
  • Dimming Zigbee
    No
  • No dim function
    Yes
  • Light sharing
    Symmetric
  • Energy efficiency class of the light source according to EU regulation 2019/2015
    C
  • Degree of protection (IP)
    IP65
  • Ball-proof
    No
  • Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24
    Yes
  • Emergency power supply integrated
    No
  • Filament test according to IEC 60695-2-11
    650 °C - 30 s
  • Rated luminous flux according to IEC 62722-2-1
    30000 lm
  • Colour of light
    White
  • Colour rendering index CRI
    80-89
  • Power factor
    0.90
  • Colour of light adjustable
    No
  • Luminous flux adjustable
    Positions
  • Length
    280.00 mm
  • Number of poles
    3
  • With protective cover
    Yes
  • Operation by Bluetooth
    No
  • Lamp type
    LED not exchangeable
  • Suitable for number of light sources
    0
  • Lamp holder
    None
  • Housing colour
    Black
  • Nominal voltage
    220 ... 240 V
  • Exchangeable control gear
    No
  • Dimming 0-10 V
    No
  • Dimming DALI
    No
  • Dimming DSI
    No
  • Dimming phase cut-on
    No
  • Dimming LineSwitch
    No
  • Dimming mains voltage modulation
    No
  • Dimming RF
    No
  • Dimming Touch and Dim
    No
  • Dimming with push-button
    No
  • Light distributor
    None
  • Reflector
    None
  • Rated life time L70/B50 at 25 °C
    70000 h
  • Impact strength
    IK08
  • Protection class
    I
  • Rated ambient temperature according to IEC 62722-2-1
    -20 ... +45 °C
  • Suitable for emergency lighting
    No
  • Max. system power
    200 W
  • Luminaire efficacy
    150 lm/W
  • Colour temperature
    4000 ... 4000 K
  • Photobiological safety according to EN 62471
    RG1
  • Constant light output (CLO)
    No
  • Beam angle adjustable
    No
  • Height/depth
    150.00 mm
  • Outer diameter
    280.00 mm
  • Connection type
    Other
  • Max. number of luminaires per miniature circuit breaker B16 (MCB)
    1
  • Meets min. EIA service life criterion L90 (at 50,000 hours at tq = 25°C)
    No

Dane producenta

Opakowania zbiorcze

Rodzaj opakowania Karton
Ilość 1 szt.
Waga (kg) 2,356
Objętość (m3) 0,012
Szerokość (m) 0,290
Długość (m) 0,300
Głębokość (m) 0,140
