Electronic ballast QT-FIT8 2x58 4008321294289

Name: Electronic ballast QT-FIT8 2x58
Brand: LEDVANCE
SKU: OCS080LEDV
Price: 90.84 PLN
Availability: InStock

Index local:

OCS080LEDV

Numéro de catalogue:

4008321294289

Code EAN:

4008321294289

Cliquer sur la photo pour l'agrandir

Producteur: LEDVANCE

Length [mm]: 360

Input voltage [V]: 198-264

DC rated voltage [V]: 185-264

Voir la description complète

Prix:

90,84 zł

gross / pcs.

(y compris la TVA 23%)

Accessible 25 pcs.

Quantité pcs.

(plusieurs:

)

Ajouter à la demande de devis

Ajouter au presse-papiers

Imprimer

Renseignez-vous sur le produit

Description du produit Données techniques Détails du fabricant Emballage en vrac Fichiers à télécharger

Description du produit

Product benefits:
Long lamp life
Frequent switching on/off has no negative impact
Automatic restart after lamp replacement
Perfect lamp start for motion sensor applications
VDE/VDE EMC certified system
Very high efficiency thanks to self-disconnect technology
SE lifetime [h]: 50000

Données techniques

Length [mm]

360
DC rated voltage [V]

185-264
Width [mm]

thirty
Height [mm]

28
PKWIU

27.11.50

Input voltage [V]

198-264
Distance of mounting holes, length [mm]

350
Darkening

NO
Temperature range [°C]

35

Autres données techniques

Model

Electronic
Dimming 0-10 V

No
Dimming DALI

No
Dimming DMX

No
Ściemniacz GPRS

No
Dimming manufacturer's proprietary system

No
Dimming phase cut-off

No
Dimming programmable

No
Dimming Sine Wave Reduction

No
Dimming Zigbee

No
No dim function

Yes
For lamp type HM

No
For lamp type LS

No
For lamp type T16

No
For lamp type T26

No
For lamp type T-R

No
For lamp type TC-D

No
For lamp type TC-DEL

No
For lamp type TC-L

No
For lamp type TC-S

No
For lamp type TC-T

No
Suitable for lamp power (2 lamps)

58 ... 58 W
Suitable for lamp power

58 ... 58 W
Housing

Metal housing
Protection class

I
Height

28.0 mm

Multiwatt model

No
Dimming 1-10 V

No
Dimming DSI

No
Dimming potentiometer (integrated)

No
Dimming LineSwitch

No
Dimming mains voltage modulation

No
Dimming phase cut-on

No
Dimming RF

No
Dimming Touch and Dim

No
Dimming with push-button

No
For lamp type HI

No
For lamp type HS

No
For lamp type T7

No
For lamp type T16-R

No
For lamp type T38

No
For lamp type T-U

No
For lamp type TC-DD

No
For lamp type TC-F

No
For lamp type TC-QEL

No
For lamp type TC-SEL

No
For lamp type TC-TEL

No
Suitable for number of lamps

2 ... 2
Nominal voltage

220 ... 240 V
Degree of protection (IP)

IP20
Length

360.0 mm

Détails du fabricant

Producteur

LEDVANCE GmbH
Adresse

85748 Garching Parkring 29-33 Niemcy
E-mail

InfoPL@ledvance.com

Emballage en vrac

Une sorte de paquet	Torebka	Karton
Quantité	1 pcs.	20 pcs.
poids (kg)	0,264	5,442
Volume (m3)	-	0,008
Largeur (m)	-	0,130
Longueur (m)	-	0,390
Profondeur (m)	-	0,160
