Name: DAMP PROOF VALUE Hermetic LED luminaire 25W 3000lm IP65 4000K NW 1500mm gray
Brand: LEDVANCE
SKU: OWF075LEDV
Price: 288.68 PLN
Availability: BackOrder

Light color [K]

3500-4800 (natural)
beam angle [°]

115
Color

Gray
Power [W]

25
Rated voltage [V]

230
Output current [mA]

180
Luminous efficiency [lm/W]

120
luminous flux [lm]

3000
Durability [h]

50000
Electrical endurance (number of cycles)

100000
Power factor [λ]

≥0.90
cri (ra)

>80
PKWIU

27.40.25

Length [mm]

1500
Protection class

II
Housing material

Polycarbonate
Installation

Surface-mounted
Initial starting current [A]

11
Family

DAMP PROOF VALUE
Level of security

IP65
Width [mm]

77
Height [mm]

66
Degree of mechanical protection

IK08
Color Temperature [K]

4000
Light-emitting surface material

Polycarbonate

Autres données techniques

Suitable for wall mounting

Yes
Suitable for ceiling mounting

Yes
Suitable for surface mounting

Yes
Suitable for clamp-mounting

No
Lamp type

LED not exchangeable
Suitable for number of light sources

0
Surface protection housing

Untreated
Material cover

Plastic, opal
Voltage type

AC
Nominal current

140 ... 140 mA
With control gear

Yes
Dimmable

No
Dimming 1-10 V

No
Dimming DALI-2

No
Dimming DSI

No
Dimming mains voltage modulation

No
Dimming phase cut-on

No
Dimming potentiometer (integrated)

No
Dimming Touch and Dim

No
Dimming with push-button

No
Light sharing

Symmetric
Light outlet

Direct
Degree of protection (IP), front side

IP65
Max. number of luminaires per miniature circuit breaker B16 (MCB)

55
Impact strength

IK08
Rated ambient temperature according to IEC 62722-2-1

-20 ... 40 °C
With switch

No
With light sensor

No
With air slots

No
Skuteczność świetlna oprawy

120 ... 120 lm/W
Znamionowy strumień świetlny zgodnie z normą IEC 62722-2-1

3000 ... 3000 lm
Colour temperature

4000 ... 4000 K
Power factor

0.9
Height/depth

68 mm
Type of wiring

Suitable for through wiring
Współczynnik harmonicznych (THD)

25 %
Photobiological safety according to EN 62471

RG0
Luminous flux adjustable

No
Operation by Bluetooth

No
Compatible with Google Assistant

No
IFTTT support available

No

Suitable for suspended mounting

No
Suitable for built-in mounting

No
Suitable for light line configuration

No
Suitable for workplace according to EN 12464-1

No
With light source

Yes
Housing material

Plastic
Housing colour

Grey
Type of grid

Matt
Nominal voltage

220 ... 240 V
Type of control gear

Electronic ballast
Exchangeable control gear

No
Dimming 0-10 V

No
Dimming DALI

No
Dimming DMX

No
Dimming manufacturer's proprietary system

No
Dimming phase cut-off

No
Dimming programmable

No
Dimming RF

No
Dimming Zigbee

No
Light distributor

Diffuser lens/optic/panel
Beam angle

Extreme wide beam >80°
Rated life time L70/B50 at 25 °C

50000 h
Maks. liczba opraw na wyłącznik nadprądowy C10

43
Max. number of luminaires per miniature circuit breaker C16 (MCB)

69
Protection class

I
Suitable for emergency lighting

No
With movement sensor

No
Covering of the luminaire with thermally insulating material possible

No
Filament test according to IEC 60695-2-11

850 °C - 30 s
Max. system power

25 W
Colour of light

White
Colour rendering index CRI

80-89
Width

77 mm
Length

1500 mm
Number of poles

3
Connection type

Push-in clamp
Colour of light adjustable

No
Beam angle adjustable

No
Compatible with Apple HomeKit

No
Compatible with Amazon Alexa

No
Kuloodporność zgodnie z DIN 18032-3

No

Une sorte de paquet	Skrzynia	Karton
Quantité	1 pcs.	6 pcs.
poids (kg)	2,076	13,686
Volume (m3)	0,009	0,063
Largeur (m)	1,510	0,180
Longueur (m)	0,070	1,530
Profondeur (m)	0,080	0,230

DAMP PROOF VALUE Hermetic LED luminaire 25W 3000lm IP65 4000K NW 1500mm gray 4058075300866
