COMPACT LED EVO P Luminaire 230V 42W 4800lm IP20/IP44 p/t NW II class 595x595 opal white 628481

Indeks lokalny:
OWG199LENA
Numer katalogowy:
628481
Kod EAN:
5905963628481
Producent: LENA LIGHTING
Light color [K]: 3500-4800 (natural)
Depth [mm]: 71
Energy class: A+
Cena:
505,16 zł
gross / szt.
(w tym VAT 23%)
do 4 tygodni
Na zamówienie
Ilość szt.
(wielokrotność:
1
)
Dodaj do zapytania ofertowego
Dodaj do schowka
Drukuj

Opis produktu

Characteristics:

New compact LED luminaire from the COMPACT EVO series, designed for flush mounting in modular and plasterboard ceilings. It is equipped with energy-saving LED GO! and evenly illuminated diffuser, ensuring low glare. The frame is made of plastic. Its assembly and electrical connection do not require disassembly of the diffuser.

Application:

The luminaire is designed for indoor use in offices or general utility rooms. It works well as the main source of light and is conducive to work that requires concentration. The luminaire is used both in new investments and when replacing traditional energy-intensive luminaires with energy-saving LED solutions.

Special features:

  • Internal tightness degree : IP20,
  • Degree of external tightness: IP44.

Dane techniczne

  • Light color [K]
    3500-4800 (natural)
  • Energy class
    A+
  • Shade
    PC
  • LED
    Yes
  • Power [W]
    42
  • Rated voltage [V]
    230
  • Luminous efficiency [lm/W]
    112
  • luminous flux [lm]
    4800
  • Height [mm]
    595
  • Color Temperature [K]
    4000
  • Depth [mm]
    71
  • Protection class
    II
  • Color
    White
  • Material
    ABS
  • Installation
    Flush-mounted
  • Family
    COMPACT LED EVO P
  • Level of security
    IP20
  • Width [mm]
    595
  • Lampshade type
    Opal
  • cri (ra)
    >80

Pozostałe dane techniczne

  • Suitable for wall mounting
    No
  • Suitable for ceiling mounting
    Yes
  • Suitable for surface mounting
    No
  • Lamp type
    LED not exchangeable
  • Suitable for number of light sources
    1
  • Material cover
    Plastic, opal
  • With control gear
    Yes
  • Dimming 1-10 V
    No
  • Dimming DMX
    No
  • Dimming potentiometer (integrated)
    No
  • Dimming LineSwitch
    No
  • Dimming mains voltage modulation
    No
  • Dimming phase cut-on
    No
  • Dimming RF
    No
  • Dimming Touch and Dim
    No
  • Dimming with push-button
    No
  • No dim function
    Yes
  • Rated life time L70/B50 at 25 °C
    125000 h
  • Degree of protection (IP)
    IP20
  • Protection class
    II
  • With movement sensor
    No
  • Max. system power
    42 W
  • Colour temperature
    4000 ... 4000 K
  • Power factor
    0.95
  • Height/depth
    71 mm
  • Suitable for suspended mounting
    No
  • Suitable for built-in mounting
    Yes
  • Suitable for light line configuration
    No
  • With light source
    Yes
  • Housing colour
    White
  • Type of control gear
    LED operating device current-controlled
  • Dimming 0-10 V
    No
  • Dimming DALI
    No
  • Dimming DSI
    No
  • Ściemniacz GPRS
    No
  • Dimming manufacturer's proprietary system
    No
  • Dimming phase cut-off
    No
  • Dimming programmable
    No
  • Dimming Sine Wave Reduction
    No
  • Dimming Zigbee
    No
  • Ściemniacz zależny od statecznika
    No
  • Klasa efektywności energetycznej zamontowanego źródła światła
    A++, A+, A (LED)
  • Żywotność znamionowa L90/B10 przy 25°C
    40000 h
  • Impact strength
    IK07
  • Suitable for emergency lighting
    No
  • With light sensor
    No
  • Rated luminous flux according to IEC 62722-2-1
    4800 lm
  • Luminaire efficacy
    112 lm/W
  • Width
    595 mm
  • Length
    595 mm

Dane producenta

  • Producent
    Lena Lighting S.A
  • Adres
    63-000 Środa Wielkopolska Kórnicka 52 Polska
