Ultrafast gS M2UQgS/350A/690 fuse-link 004724230

Name: Ultrafast gS M2UQgS/350A/690 fuse-link
Brand: ETI POLAM
SKU: ABM008ETIP
Price: 122.94 PLN

local index:

ABM008ETIP

Catalog No:

004724230

EAN code:

3838895757313

Click on the photo to enlarge

Manufacturer: ETI POLAM

Characteristic: qS

Rated voltage [V]: 690

Rated current [A]: 350

See full description

Price:

122,94 €

gross / pcs.

(including VAT 23%)

186,27 € gross/kg.

Delivery in 3h

up to 2 weeks (business days)

Pickup in 1h

Quantity pcs.

(multiplicity:

)

Add to clipboard

Ask about the product

Product description Technical data Manufacturer details Bulk packaging Files to download

Product description

Type M fuse links are designed to be mounted in industrial fuse bases of the appropriate size. The fuse-links with the gS characteristic are designed to protect semiconductors and power cables of the converter.

Technical data

Characteristic

qS
Rated current [A]

350
Weight [g]

660
PKWIU

27.12.21.0

Rated voltage [V]

690
Power dissipation [W]

41
Rated short-circuit capacity [kA]

100

Other technical data

Rated current

350 A
Type of fuse status indicator

Top fuse status indicator

Utilization category

Other

Manufacturer details

Manufacturer

ETI Polam Sp. z o.o.
Address

06-100 Pułtusk Jana Pawła II 18 Polska
E-mail

etipolam@etipolam.com.pl

Bulk packaging

A kind of package	Pudełko	Pudełko	Pudełko	Pudełko
Quantity	3 pcs.	15 pcs.	3 pcs.	15 pcs.
Weight (kg)	2,640	13,200	2,640	13,200
Volume (m3)	0,004	0,026	0,004	0,026
Width (m)	0,165	0,360	0,165	0,360
Length (m)	0,105	0,200	0,105	0,200
Depth (m)	0,246	0,360	0,246	0,360
