Ultrafast fuse link S2UQ01/110/630A/690 004394128
local index:
ABM032ETIP
Catalog number:
004394128
Price:
611,86 zł
gross / pcs.
(including VAT 23%)
941,32 zł gross/kg.
On request
Quantity pcs.
(multiplicity:
1
)
Add to inquiry
Add to clipboard
Print
Ask about the product
Product description
S 110mm fuse-links, sizes 1, 2, 3, are designed to be screwed directly to busbars, or in the US1..3-1/80-110 base.
Technical data
-
CharacteristicaR
-
Rated current [A]630
-
Weight [g]650
-
PKWIU27.12.21.0
-
Rated voltage [V]690
-
Power dissipation [W]85
-
Rated short-circuit capacity [kA]200
Other technical data
-
Rated current630 A
-
Type of fuse status indicatorTop fuse status indicator
-
Utilization categoryaR (accompanied semiconductor protection)
Manufacturer details
-
ManufacturerETI Polam Sp. z o.o.
-
Address06-100 Pułtusk Jana Pawła II 18 Polska
-
E-mail
Bulk packaging
| A kind of package | Pudełko | Pudełko | Pudełko | Pudełko |
| Quantity | 1 pcs. | 16 pcs. | 1 pcs. | 16 pcs. |
| Weight (kg) | 0,670 | 10,720 | 0,670 | 10,720 |
| Volume (m3) | 0,001 | 0,017 | 0,001 | 0,017 |
| Width (m) | 0,076 | 0,230 | 0,076 | 0,230 |
| Length (m) | 0,063 | 0,250 | 0,063 | 0,250 |
| Depth (m) | 0,154 | 0,290 | 0,154 | 0,290 |
