Ultrafast fuse link S1UQ01/110/315A/1000 004303121
local index:
ABM044ETIP
Catalog No:
004303121
Price:
140,38 €
gross / pcs.
(including VAT 23%)
280,76 € gross/kg.
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to inquiry
Add to clipboard
Print
Ask about the product
Product description
S 110mm fuse-links, sizes 1, 2, 3, are designed to be screwed directly to busbars, or in the US1..3-1/80-110 base.
Technical data
-
CharacteristicaR
-
Rated current [A]315
-
Rated short-circuit capacity [kA]200
-
Rated voltage [V]1000
-
Weight [g]500
-
PKWIU27.12.21.0
Other technical data
-
Rated current315 A
-
Type of fuse status indicatorTop fuse status indicator
-
Utilization categoryaR (accompanied semiconductor protection)
Manufacturer details
-
ManufacturerETI Polam Sp. z o.o.
-
Address06-100 Pułtusk Jana Pawła II 18 Polska
-
E-mail
Bulk packaging
| A kind of package | Pudełko | Pudełko |
| Quantity | 1 pcs. | 26 pcs. |
| Weight (kg) | 0,620 | 16,120 |
| Volume (m3) | 0,001 | 0,017 |
| Width (m) | 0,067 | 0,230 |
| Length (m) | 0,050 | 0,250 |
| Depth (m) | 0,136 | 0,290 |
