Ultra-fast fuse-link S1UQ U/110/200A/690 004333114
local index:
ABM004ETIP
Catalog No:
004333114
EAN code:
3838895733614
Price:
55,82 €
gross / pcs.
(including VAT 23%)
124,04 € gross/kg.
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
S110 size 1 and 2 fuse-links are designed to be screwed directly to busbars or in the base S1.3-1/80-112
Technical data
-
CharacteristicaR
-
Rated current [A]200
-
Weight [g]450
-
AC rated voltage [V]690
-
DC rated voltage [V]440
-
Power dissipation [W]58
-
Rated short-circuit capacity [kA]~50/-25
-
PKWIU27.12.21.0
Other technical data
-
Rated current200 A
-
Type of fuse status indicatorTop fuse status indicator
-
Utilization categoryaR (accompanied semiconductor protection)
Manufacturer details
-
ManufacturerETI Polam Sp. z o.o.
-
Address06-100 Pułtusk Jana Pawła II 18 Polska
-
E-mail
Bulk packaging
| A kind of package | Pudełko | Pudełko | Pudełko | Pudełko |
| Quantity | 3 pcs. | 24 pcs. | 3 pcs. | 24 pcs. |
| Weight (kg) | 1,260 | 10,080 | 1,260 | 10,080 |
| Volume (m3) | 0,001 | 0,017 | 0,001 | 0,017 |
| Width (m) | 0,065 | 0,230 | 0,065 | 0,230 |
| Length (m) | 0,139 | 0,250 | 0,139 | 0,250 |
| Depth (m) | 0,150 | 0,290 | 0,150 | 0,290 |
