Ultra-fast fuse-link S00CUQ U/80/63A/690 004331011

local index:
ABM031ETIP
Catalog No:
004331011
EAN code:
5904722913127
Manufacturer: ETI POLAM
Characteristic: aR
DC rated voltage [V]: 440
Rated current [A]: 63
Price:
26,62 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Print

Product description

S80 fuse-links, sizes 00C, 00 and 0, are designed for mounting directly with screws to busbars or in the US00-1/80 base, while S97 fuse-links, size 0, are mounted directly to busbars.

Technical data

  • Characteristic
    aR
  • Rated current [A]
    63
  • Weight [g]
    180
  • AC rated voltage [V]
    690
  • DC rated voltage [V]
    440
  • Power dissipation [W]
    20
  • Rated short-circuit capacity [kA]
    ~50/-25
  • PKWIU
    27.12.21.0

Other technical data

  • Rated current
    63 A
  • Type of fuse status indicator
    Top fuse status indicator
  • Utilization category
    aR (accompanied semiconductor protection)

Bulk packaging

A kind of package Pudełko Pudełko
Quantity 3 pcs. 45 pcs.
Weight (kg) 0,400 -
Volume (m3) 0,001 -
Width (m) 0,092 -
Length (m) 0,137 -
Depth (m) 0,068 -

Files to download
