Three-position twist switch white 2 NO contacts illuminated 24V AC/DC nickel-plated ring ST22-P3L.B-20-LED\24AC/DC

local index:
AKS058SPAM
Catalog No:
ST22-P3L.B-20-LED\24AC/DC
EAN code:
5907723053168
Manufacturer: SPAMEL
Color: White
Accurate color: White
Price:
26,33 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Application The SP22 control buttons are used to connect or disconnect currents up to 2.5 A, light and sound signaling in machine panels and control cabinets. Control buttons and signal lamps SP22 have a modular structure.

Technical data

  • Color
    White
  • Accurate color
    White

Other technical data

  • Number of switch positions
    3
  • Suitable for illumination
    Yes
  • Colour button
    White
  • Width opening
    22 mm
  • Spring-return
    No
  • Supply voltage
    24 ... 230 V
  • Number of contacts as normally closed contact
    0
  • Type of electric connection
    Screw connection
  • Material front ring
    Plastic
  • Type of control element
    Toggle
  • With light source
    Yes
  • Hole diameter
    22 mm
  • Switching function latching
    Yes
  • Degree of protection (IP)
    IP65
  • Number of contacts as normally open contact
    2
  • Number of contacts as change-over contact
    0
  • With front ring
    Yes
  • Colour front ring
    Grey
