Signal lamp 22mm red BA9S 230V AC ST23 ST22-LC-230-BA9S\.

local index:
AKS810SPAM
Catalog No:
ST22-LC-230-BA9S\.
EAN code:
5907723008717
Manufacturer: SPAMEL
Color: Red
Level of security: IP65
Diameter [mm]: 22
Price:
11,19 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Signal lamp 22mm red BA9S 230V AC ST23

Technical data

  • Color
    Red
  • Diameter [mm]
    22
  • Level of security
    IP65
  • Accurate color
    Red

Other technical data

  • Number of indicator lights
    1
  • Type of lamp socket
    BA9s
  • Rated operating voltage Ue
    24 ... 230 V
  • Type of electric connection
    Screw connection
  • Type of lens
    Flat
  • Width opening
    22 mm
  • With front ring
    Yes
  • Colour front ring
    Grey
  • Colour lens
    Red
  • With light source
    Yes
  • Voltage type
    AC
  • Construction type lens
    Round
  • Hole diameter
    22 mm
  • Height opening
    22 mm
  • Material front ring
    Plastic
  • Degree of protection (IP)
    IP65
