Signal lamp 22mm red 24V AC/DC BA9S SP22-LC-24-LED\AC/DC

local index:
AKS022SPAM
Catalog No:
SP22-LC-24-LED\AC/DC
EAN code:
5907723060593
Manufacturer: SPAMEL
Color: Red
Lens shape: Round
Face ring material: Plastic
Price:
12,37 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Signal lamp 22mm red 24V AC/DC BA9S

Technical data

  • Color
    Red
  • Face ring material
    Plastic
  • Hole diameter [mm]
    22.3
  • Lens shape
    Round
  • Level of security
    IP65
  • Accurate color
    Red

Other technical data

  • Number of indicator lights
    1
  • Type of lamp socket
    BA9s
  • Rated operating voltage Ue
    24 ... 230 V
  • Type of electric connection
    Screw connection
  • Type of lens
    Flat
  • Width opening
    22 mm
  • With front ring
    Yes
  • Colour front ring
    Grey
  • Colour lens
    Red
  • With light source
    Yes
  • Voltage type
    AC/DC
  • Construction type lens
    Round
  • Hole diameter
    22 mm
  • Height opening
    22 mm
  • Material front ring
    Plastic
  • Degree of protection (IP)
    IP65
