SERIES 22 25A 4-pole AgSnO2 installation contactor 223402304320PAS

Installation contactor 25 A - 4 poles from the 22 series, from the manufacturer FINDER. The product part number is 22.34.0.230.4320PAS.

• NO contact with ≥ 3 mm gap, double contact gap.
• Continuous operation possible for coil and contacts.
• AC/DC power supply (with protective varistor).
• Safe separation (increased insulation) between coil and contacts.
• Mechanical and LED indicators as standard.
• Compliant with EN 61095: 2009.
• For railway applications; materials in accordance with the characteristics of flammability (EN 45545-2 + A1: 2016).
• For mounting on a 35mm DIN rail (EN 60715).
• AgSnO2 contact material dedicated to switching lamps and loads with high peak current on - off.
• Number of contacts: 4 Z, 3 mm (or 3 NO + 1 NO or 2 NO + 2 ).
• Distance between NO contacts  ≥ 3 mm; distance for NC contacts (after opening the contact) ≥ 1.5 mm.
• Rated current for AC3 / AC-7b: 10 A.
• Rated current for AC-5a (for 1 contact at 250 V): 15 A.
• Rated current for AC-7c: 10 A.
• Permissible load:
  • 230V incandescent/halogen [W]: 2000.
  • fluorescent lamps with stat. electronic [W]: 800.
  • fluorescent lamps with stat. electromechanical [W]: 500.
  • CFL [W]: 200.
  • 230 V LED [W]: 200.
  • NN halogen or LED with stat. electron. [W]: 200.
  • NN halogen or LED with stat. electromechanical [W]: 800.
• Coil data:
  • Rated voltage (UN): 12 - 24 - 48 - 60 - 120 - 230 V  DC/AC (50/60Hz).
  • AC/DC power consumption: 2/2.2 VA (50Hz)/W.
  • Supply voltage range: ( 0.8…1.1)UN DC/AC (50/60 Hz).
  • Backup voltage: 0.4 UN DC/AC (50/60 Hz).
  • Drop-out voltage: 0.1 UN DC/AC (50/60 Hz).
• Coil-contact insulation strength (1.2/50 µ ;s): 6 kV.
