Residual current circuit breaker EFI6-P4 AC 40/0.03 6kA 4-pole 002061652

local index:
ARP031ETIP
Catalog No:
002061652
EAN code:
3838895867548
Manufacturer: ETI POLAM
Rated frequency [Hz]: 50/60
Installation: On the TH-35 rail
Rated voltage [V]: 415
Price:
47,51 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Accessible 8 pcs.
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Residual current circuit breaker with rated breaking capacity 6kA.

  • Number of poles 3+N
  • Clamp capacity: 1 -25 mm2
  • Rated operating current: 0.03IDn (mA)
  • Impact current: 0.4kA

Technical data

  • Rated frequency [Hz]
    50/60
  • Rated voltage [V]
    415
  • Level of security
    IP20
  • Installation
    On the TH-35 rail
  • Rated current [A]
    40
  • PKWIU
    27.12.22.0

Other technical data

  • Number of poles
    4
  • Rated fault current
    30 A
  • Rated impulse withstand voltage Uimp
    6 kV
  • Leakage current type
    AC
  • Frequency
    50/60 Hz
  • Width in number of modular spacings
    4
  • Ambient temperature during operating
    -25 ... 55 °C
  • Connectable conductor cross section solid-core
    1 ... 25 mm²
  • Rated current
    40 A
  • Rated insulation voltage Ui
    440 V
  • Mounting method
    DIN rail
  • Short-circuit breaking capacity (Icw)
    6 kA
  • Degree of protection (IP)
    IP20
  • Built-in depth
    68 mm
  • Connectable conductor cross section multi-wired
    1 ... 25 mm²

Bulk packaging

A kind of package Pudełko Pudełko
Quantity 1 pcs. 27 pcs.
Weight (kg) 0,303 9,395
Volume (m3) 0,001 0,017
Width (m) 0,075 0,233
Length (m) 0,078 0,253
Depth (m) 0,092 0,287
