Power contactor TeSys TVS AC3 25A 3P 1NO coil 380VAC LC1E2510Q5
local index:
ATA224SCHN
Catalog No:
LC1E2510Q5
EAN code:
3606480328565
Manufacturer:
SCHNEIDER ELECTRIC
AC control voltage [V]: 380
Price:
42,19 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Power contactor TeSys TVS AC3 25A 3P 1NO coil 380VAC
Technical data
-
AC control voltage [V]380
-
PKWIU27.12.24.0
Other technical data
-
Rated control supply voltage AC 50 Hz380 ... 380 V
-
Rated operation current Ie at AC-1, 400 V36 A
-
Rated operation power at AC-3, 400 V11 kW
-
Number of auxiliary contacts as normally open contact1
-
Type of electrical connection of main circuitScrew connection
-
Number of normally open contacts as main contact3
-
Voltage type for actuatingAC
-
Rated operation current Ie at AC-3, 400 V25 A
-
Modular versionNo
-
Number of auxiliary contacts as normally closed contact0
-
Number of normally closed contacts as main contact0
