Power contactor TeSys K AC3 9A 3P 1NC coil 48VAC box terminals LC1K0901E7

local index:
ATA053SCHN
Catalog No:
LC1K0901E7
EAN code:
3389110374759
Manufacturer: SCHNEIDER ELECTRIC
Number of poles: 3
Control circuit voltage [V]: 48
Contact: 1NZ
Price:
29,62 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Power contactor TeSys K AC3 9A 3P 1NC coil 48VAC box terminals

Technical data

  • Number of poles
    3
  • Contact
    1NZ
  • PKWIU
    27.12.24.0
  • Control circuit voltage [V]
    48
  • Rated operational current [A]
    9

Other technical data

  • Rated control supply voltage AC 50 Hz
    48 ... 48 V
  • Voltage type for actuating
    AC
  • Rated operation current Ie at AC-3, 400 V
    9 A
  • Rated operation current Ie at AC-4, 400 V
    6 A
  • Modular version
    No
  • Number of auxiliary contacts as normally closed contact
    1
  • Number of normally closed contacts as main contact
    0
  • Rated control supply voltage AC 60 Hz
    48 ... 48 V
  • Rated operation current Ie at AC-1, 400 V
    20 A
  • Rated operation power at AC-3, 400 V
    4 kW
  • Rated operation power at AC-4, 400 V
    2.2 kW
  • Number of auxiliary contacts as normally open contact
    0
  • Type of electrical connection of main circuit
    Screw connection
  • Number of normally open contacts as main contact
    3
