382983
0
Power contactor TeSys K AC3 12A 3P 1NO coil 380/400VAC box terminals LC1K1210Q7
local index:
ATA831SCHN
Catalog No:
LC1K1210Q7
EAN code:
3389110789768
Manufacturer:
SCHNEIDER ELECTRIC
AC control voltage [V]: 380/400
Price:
54,98 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Power contactor TeSys K AC3 12A 3P 1NO coil 380/400VAC box terminals
Technical data
-
AC control voltage [V]380/400
-
PKWIU27.12.24.0
Other technical data
-
Rated control supply voltage AC 50 Hz380 ... 400 V
-
Voltage type for actuatingAC
-
Rated operation current Ie at AC-3, 400 V12 A
-
Rated operation current Ie at AC-4, 400 V12 A
-
Rated operation power NEMA5.60 kW
-
Number of auxiliary contacts as normally open contact1
-
Type of electrical connection of main circuitScrew connection
-
Number of normally open contacts as main contact3
-
Rated control supply voltage AC 60 Hz380 ... 400 V
-
Rated operation current Ie at AC-1, 400 V20 A
-
Rated operation power at AC-3, 400 V5.5 kW
-
Rated operation power at AC-4, 400 V5.5 kW
-
Modular versionYes
-
Number of auxiliary contacts as normally closed contact0
-
Number of normally closed contacts as main contact0
