Power contactor TeSys K AC1 20A 4P 2NO 2NC coil 220/230VAC LC1K09008M7
local index:
ATA093SCHN
Catalog No:
LC1K09008M7
EAN code:
3389110488876
Manufacturer:
SCHNEIDER ELECTRIC
Number of poles: 4
Control circuit voltage [V]: 220
Contact: 2NO+2NC
Price:
33,31 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Power contactor TeSys K AC1 20A 4P 2NO 2NC coil 220/230VAC
Technical data
-
Number of poles4
-
Contact2NO+2NC
-
PKWIU27.12.24.0
-
Control circuit voltage [V]220
-
Rated operational current [A]9
Other technical data
-
Rated control supply voltage AC 50 Hz220 ... 230 V
-
Voltage type for actuatingAC
-
Modular versionNo
-
Number of auxiliary contacts as normally closed contact0
-
Number of normally closed contacts as main contact2
-
Rated control supply voltage AC 60 Hz220 ... 230 V
-
Rated operation current Ie at AC-1, 400 V20 A
-
Number of auxiliary contacts as normally open contact0
-
Type of electrical connection of main circuitScrew connection
-
Number of normally open contacts as main contact2
