Power contactor TeSys K 9A 3P 1NC coil 12VDC box terminals LP1K0901JD
local index:
ATD107SCHN
Catalog No:
LP1K0901JD
EAN code:
3389110496796
Click on the photo to enlarge
Manufacturer:
SCHNEIDER ELECTRIC
DC control voltage [V]:
12
See full description
Price:
52,84 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
2 weeks
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to cart
Add to clipboard
Print
Ask about the product
Product description
Technical data
Files to download
Product description
Power contactor TeSys K 9A 3P 1NC coil 12VDC box terminals
Technical data
DC control voltage [V]
12
PKWIU
27.12.24.0
Other technical data
Rated control supply voltage DC
12 ... 12 V
Rated operation current Ie at AC-1, 400 V
20 A
Rated operation power at AC-3, 400 V
4 kW
Rated operation power at AC-4, 400 V
2.2 kW
Number of auxiliary contacts as normally open contact
0
Type of electrical connection of main circuit
Screw connection
Number of normally open contacts as main contact
3
Voltage type for actuating
DC
Rated operation current Ie at AC-3, 400 V
9 A
Rated operation current Ie at AC-4, 400 V
6 A
Modular version
No
Number of auxiliary contacts as normally closed contact
1
Number of normally closed contacts as main contact
0
Files to download
PEP ecopassport SCHN-2015-025-EN_1.pdf
EoLI_ENVEOLI1503003_1.pdf
UK_Doc_LC_K_LP_K06-16_SC16040406A-UK.docx.pdf
