el12 Electrical apparatus fuses Circuit breakers with "B" characteristic OVERCURRENT SWITCH S 301 B 6 1P 6A 6KA
OVERCURRENT SWITCH S 301 B 6 1P 6A 6KA
OVERCURRENT SWITCH S 301 B 6 1P 6A 6KA

Click on the photo to enlarge

OVERCURRENT SWITCH S 301 B 6 1P 6A 6KA
OVERCURRENT SWITCH S 301 B 6 1P 6A 6KA
LEGRAND

OVERCURRENT SWITCH S 301 B 6 1P 6A 6KA 403353

local index:
ABB207LEGR
Catalog No:
403353
EAN code:
3414970386182
Price:
4,98 €
gross / pcs.
including VAT 23%
Availability:
up to a week (working days)
Delivery:
From 3,45 € (prepaid courier) Details
Quantity:
Goods at a promotional price can only be purchased in the quantity available in stock pcs.
Delivery methods:
Metody dostawy
details
Payment methods:
Metody płatności
details
Go to section:
Product description Technical data

Product description

Current circuit breaker with type B characteristics and 6A rated current. The LE-403353 switch is intended for mounting on a DIN TS-35 rail.

Overcurrent circuit breakers with B characteristics are designed to protect lighting, control and plug socket circuits against the effects of short circuits and overloads.

Print the product sheet Report an error

Technical data

  • Characteristic
    b
  • Rated current [A]
    6
  • Width in modules
    1
  • Rated short-circuit breaking capacity [A]
    6000
  • Rated voltage [V]
    230
  • Family
    Q10
  • Weight [g]
    120

Other technical data

  • Release characteristic
    B
  • Number of protected poles
    1
  • Rated voltage
    230 V
  • Rated impulse withstand voltage Uimp
    4 kV
  • Voltage type
    AC
  • Do instalacji podtynkowych
    yes
  • Additional equipment possible
    yes
  • Built-in depth
    44 mm
  • Number of poles (total)
    1
  • Rated current
    6 A
  • Rated insulation voltage Ui
    500 V
  • Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
    6 kA
  • Current limiting class
    3
  • Concurrently switching neutral conductor
    no
  • Width in number of modular spacings
    1
  • Degree of protection (IP)
    IP20

Catalog cards, diagrams, certificates

F01547EN-01.pdf
LGRP-00763-V01.01-EN.pdf
LEGRAND+WYŁĄCZNIK+NADMIAROWO-PRĄDOWY+S+301+B+10+1P+10+A+6+KA.jpg.pdf
legs301.jpg.pdf
Karta katalogowa(351).pdf.pdf
