OVERCURRENT CIRCUIT BREAKER 6KA 3P C 06A S-A00-S7-3P-C06

local index:
ABC024BEMK
Catalog number:
S-A00-S7-3P-C06
EAN code:
5908311361641
Manufacturer: BEMKO
Price:
56,68 zł
gross / pcs.
(including VAT 23%)
2 weeks
On request
Quantity pcs.
(multiplicity:
1
)
Add to inquiry
Add to clipboard
Print

Technical data

Other technical data

  • Built-in depth
    50 mm
  • Number of poles (total)
    3
  • Rated current
    6 A
  • Rated insulation voltage Ui
    300 V
  • Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
    6 kA
  • Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
    6 kA
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
    6 kA
  • Current limiting class
    3
  • Concurrently switching neutral conductor
    No
  • Pollution degree
    2
  • Width in number of modular spacings
    1
  • Ambient temperature during operating
    -5 ... 40 °C
  • Connectable conductor cross section solid-core
    5 ... 25 mm²
  • Release characteristic
    C
  • Number of protected poles
    3
  • Rated voltage
    230 V
  • Rated impulse withstand voltage Uimp
    4 kV
  • Voltage type
    AC
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
    6 kA
  • Frequency
    50 ... 60 Hz
  • Flush-mounted installation
    Yes
  • Over voltage category
    3
  • Additional equipment possible
    No
  • Degree of protection (IP)
    IP20
  • Connectable conductor cross section multi-wired
    5 ... 16 mm²

Manufacturer details

  • Manufacturer
    BEMKO Sp. z o.o.
  • Address
    05-850 Jawczyce Bocznicowa 13 Polska

Bulk packaging

A kind of package Pudełko Karton Paleta
Quantity 4 pcs. 40 pcs. 2000 pcs.
Weight (kg) 0,324 3,240 162,000
Width (m) 9,200 25,000 0,800
Length (m) 22,500 50,500 1,200
Depth (m) 8,200 18,800 -
